LINKHUB HH132
Model LINKHUB HH132Part no. HH132V1EAN 8033779069499
35 specifications
- ColourWhite
- Device typeCellular network router
- Ethernet LANYes
- Data network3G, 4G
- Ethernet LAN (RJ-45) ports2
- Security algorithmsAES, SSID, WPA, WPA2, WPA3
Overview
- Colour
- White
- Device type
- Cellular network router
- Ethernet LAN
- Yes
- Data network
- 3G, 4G
- Ethernet LAN (RJ-45) ports
- 2
- Security algorithms
- AES, SSID, WPA, WPA2, WPA3
- Brand
- TCL
- Category
- Cellular Network Device
- Model
- LINKHUB HH132
- Part number
- HH132V1
- EAN / UPC
- 8033779069499
- Also known as
- TCL LINKHUB HH132 Cellular network router
Specifications
35 specifications in 10 groups
Design
| Specification | Value |
|---|---|
| Device type | Cellular network router |
| Product colour | White |
| Market positioning | Home |
| LED indicators | Yes |
Ethernet LAN features
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN interface type | Gigabit Ethernet |
| DHCP client | No |
| DHCP server | Yes |
Wireless LAN features
| Specification | Value |
|---|---|
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| Number of WLAN connections (max) | 64 |
Mobile network
| Specification | Value |
|---|---|
| Data network | 3G, 4G |
| 3G standards | UMTS |
| 4G standard | LTE-FDD |
| Number of SIM cards | 1 |
| SIM card type | NanoSIM |
| Data transfer rate (LTE) (download) | 600 Mbit/s |
| Data transfer rate (LTE) (upload) | 150 Mbit/s |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 2 |
| RJ-11 ports quantity | 1 |
| Serial interface type | RJ-11 |
| Serial ports quantity | 1 |
Security
| Specification | Value |
|---|---|
| Security algorithms | AES, SSID, WPA, WPA2, WPA3 |
| IP address filtering | Yes |
| DMZ support | Yes |
| Port forwarding | Yes |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | CE, REACH, RoHS, WEEE |
| Certification | Wi-Fi |
Performance
| Specification | Value |
|---|---|
| Antenna type | Internal |
| Parental control | Yes |
Power
| Specification | Value |
|---|---|
| Power source type | AC |
| External power adapter | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 177 mm |
| Depth | 30 mm |
| Height | 127 mm |
