FRITZ!Box 6860 5G
Model FRITZ!Box 6860 5GPart no. 20003183EAN 4023125031830
48 specifications
- ColourWhite
- Device typeCellular network router
- Ethernet LANYes
- Data network3G, 4G, 5G
- Ethernet LAN (RJ-45) ports1
- Security algorithmsIPSec, WPA2, WPA3, WPS
Overview
- Colour
- White
- Device type
- Cellular network router
- Ethernet LAN
- Yes
- Data network
- 3G, 4G, 5G
- Ethernet LAN (RJ-45) ports
- 1
- Security algorithms
- IPSec, WPA2, WPA3, WPS
- Brand
- FRITZ!
- Category
- Cellular Network Device
- Model
- FRITZ!Box 6860 5G
- Part numbers
- 20003183, 20003048
- EAN / UPC
- 4023125031830, 4023125030482
- Also known as
- Box FRITZ! 6860 5G Cellular network router
Specifications
48 specifications in 14 groups
Design
| Specification | Value |
|---|---|
| Device type | Cellular network router |
| Product colour | White |
| LED indicators | WLAN, Power |
Ethernet LAN features
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN interface type | Gigabit Ethernet |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Networking standards | IEEE 802.3at |
| DHCP server | Yes |
| VoIP | Yes |
| VPN Passthrough | Yes |
| Supported network protocols | IPv6 |
| Guest access | Yes |
Wireless LAN features
| Specification | Value |
|---|---|
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11a, 802.11g, Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| WLAN data transfer rates supported | 600,2402 Mbit/s |
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| MIMO | Yes |
| Wi-Fi Protected Setup (WPS) | Yes |
Mobile network
| Specification | Value |
|---|---|
| Data network | 3G, 4G, 5G |
| 3G standards | HSPA+, UMTS |
| 4G standard | LTE-A |
| 4G bands supported | 1500,3500,3700 MHz |
| 5G bands supported | 700,800,850,900,1500,1800,2100,2300,2500,2600,3500,3800,1400 MHz |
| Number of SIM cards | 1 |
| SIM card type | NanoSIM |
| Voice over LTE (VoLTE) supported | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
Security
| Specification | Value |
|---|---|
| Security algorithms | IPSec, WPA2, WPA3, WPS |
| Network address translation (NAT) | Yes |
| Firewall | Yes |
Packaging content
| Specification | Value |
|---|---|
| Cables included | LAN (RJ-45) |
| Packaging content | FRITZ!Box 6860 5G v2 Edition International, 1 x router bracket for indoors, 1 x router bracket for outdoors (including mounting screw), 1 x PoE power adapter (PoE+, 26 W) including gigabit LAN uplink, 1 x power cable, 2 x 2.5 m LAN cable (UV-resistant), 5 x self-adhesive cable clip, 2 x adhesive pad |
Performance
| Specification | Value |
|---|---|
| Antennas quantity | 4 |
| International Protection (IP) code | IP54 |
Power
| Specification | Value |
|---|---|
| Power source type | PoE |
| Power consumption (typical) | 6.8 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -10 - 40 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 111 mm |
| Depth | 163 mm |
| Height | 31 mm |
Packaging data
| Specification | Value |
|---|---|
| User guide | Yes |
| Package width | 177 mm |
| Package depth | 97 mm |
| Package height | 240 mm |
| Package weight | 960 g |
Logistics data
| Specification | Value |
|---|---|
| Country of origin | Poland |
| Warranty period | 5 year(s) |
Other features
| Specification | Value |
|---|---|
| Data transfer rate | 1.3 Gbit/s |
