TSR-700 AV receiver
100 W 7.1 channels Surround 3D Black
Model TSR-700EAN 4957812660549
49 specifications
- ConnectivityWired & Wireless
- ColourBlack
- Power output per channel (20-20KHz@8 Ohm)100 W
- HDMI in7
- Number of HDMI outputs1
- Speakers connectivity typeBinding post
Overview
- Connectivity
- Wired & Wireless
- Colour
- Black
- Power output per channel (20-20KHz@8 Ohm)
- 100 W
- HDMI in
- 7
- Number of HDMI outputs
- 1
- Speakers connectivity type
- Binding post
- Brand
- Yamaha
- Category
- AV Receiver
- Model
- TSR-700
- Part number
- TSR-700
- EAN / UPC
- 4957812660549
- Also known as
- Yamaha TSR-700 AV receiver 100 W 7.1 channels Surround 3D Black
Specifications
49 specifications in 14 groups
Audio
| Specification | Value |
|---|---|
| Power output per channel (20-20KHz@8 Ohm) | 100 W |
| Audio output channels | 7.1 channels |
| Receiver type | Surround |
| Audio D/A Converter (DAC) | 32-bit/384kHz |
| Pre-out channels | 2.2 |
| Pre-out connectivity | Yes |
Inputs
| Specification | Value |
|---|---|
| HDMI in | 7 |
| Digital audio optical in | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| USB ports quantity | 1 |
Outputs
| Specification | Value |
|---|---|
| Number of HDMI outputs | 1 |
| Headphone outputs | 1 |
Ports & interfaces
| Specification | Value |
|---|---|
| Speakers connectivity type | Binding post |
| Connectivity technology | Wired & Wireless |
| Phono inputs (RCA) | 1 |
File formats
| Specification | Value |
|---|---|
| Audio formats supported | AAC, AIFF, ALAC, DSD, FLAC, MP3, WAV, WMA |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| Bluetooth | Yes |
| Bluetooth profiles | AAC, SBC |
Radio
| Specification | Value |
|---|---|
| Supported radio bands | AM, FM |
Optical drive
| Specification | Value |
|---|---|
| Optical drive included | No |
Storage
| Specification | Value |
|---|---|
| Card reader integrated | No |
Video
| Specification | Value |
|---|---|
| Supported graphics resolutions | 3840 x 2160, 7680 x 4320 |
| Supported video modes | 2160p, 4320p |
| 3D | Yes |
| Video upscaling | Yes |
Technical details
| Specification | Value |
|---|---|
| Audio decoders | DTS-HD, DTS:X, Dolby Atmos, Dolby Digital Plus, Dolby Surround, Dolby TrueHD |
| Audio Return Channel (ARC) | Yes |
| Apple docking | No |
| DSP programs quantity | 17 |
| Digital Signal Processing (DSP) | Yes |
| AirPlay | Yes |
| Audio input | 4 |
| Auto standby | Yes |
| Bi-amping | Yes |
| ECO mode | Yes |
| HDCP | Yes |
| HDCP version | 2.3 |
| On Screen Display (OSD) | Yes |
| Product colour | Black |
| Remote control included | Yes |
Power
| Specification | Value |
|---|---|
| Power consumption (standby) | 0.1 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 435 mm |
| Depth | 377.8 mm |
| Height | 171.4 mm |
Packaging content
| Specification | Value |
|---|---|
| AM antenna | Yes |
| FM antenna | Yes |
| User guide | Yes |
