RX-V1071 110 W 7.2 channels 3D Black
Model RX-V1071Part no. RXV-1071BLEAN 2600166000951
79 specifications
- ConnectivityWired
- Weight15.1 kg
- ColourBlack
- Power output per channel (20-20KHz@8 Ohm)110 W
- HDMI in8
- Number of HDMI outputs2
Overview
- Connectivity
- Wired
- Weight
- 15.1 kg
- Colour
- Black
- Power output per channel (20-20KHz@8 Ohm)
- 110 W
- HDMI in
- 8
- Number of HDMI outputs
- 2
- Brand
- Yamaha
- Category
- AV Receiver
- Model
- RX-V1071
- Part numbers
- RXV-1071BL, RXV-1071TI
- EAN / UPC
- 2600166000951, 4957812498814, 4957812498821
- Also known as
- Yamaha RX-V1071 110 W 7.2 channels 3D Black
Specifications
79 specifications in 14 groups
Audio
| Specification | Value |
|---|---|
| Power output per channel (20-20KHz@8 Ohm) | 110 W |
| Audio output channels | 7.2 channels |
| Power output per channel (1KHz@8 Ohm) | 165 W |
| Dynamic power per channel (4 Ohm) | 210 W |
| Dynamic power per channel (8 Ohm) | 135 W |
| Total Harmonic Distortion (THD) | 0.06% |
| Audio D/A Converter (DAC) | 24-bit/192kHz |
| Pre-out channels | 7.2 |
| Pre-out connectivity | Yes |
Inputs
| Specification | Value |
|---|---|
| HDMI in | 8 |
| Component video (YPbPr/YCbCr) in | 4 |
| Composite video in | 5 |
| S-Video inputs quantity | 5 |
| Audio (L/R) in | 10 |
| Digital audio optical in | 4 |
| Digital audio coaxial in | 3 |
| Remote (IR) input | 1 |
| AC (power) in | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Multichannel audio input type | RCA |
| Remote control in | 1 |
| USB ports quantity | 1 |
Outputs
| Specification | Value |
|---|---|
| Number of HDMI outputs | 2 |
| Component video (YPbPr/YCbCr) out | 1 |
| Composite video out | 1 |
| S-Video outputs quantity | 1 |
| Audio (L/R) out | 1 |
| Digital audio optical out | 1 |
| Digital audio coaxial out | 0 |
| Remote (IR) output | 1 |
| Headphone outputs | 1 |
| Remote control out | 1 |
Ports & interfaces
| Specification | Value |
|---|---|
| Speakers connectivity type | Banana connector |
| Connectivity technology | Wired |
| AM antenna ports quantity | 1 |
| FM antenna ports quantity | 1 |
| 12V trigger | Yes |
| 12V trigger ports quantity | 2 |
| Multichannel pre out connectivity | RCA |
| Phono inputs (RCA) | 1 |
| RS-232 ports | 1 |
File formats
| Specification | Value |
|---|---|
| Audio formats supported | FLAC, MP3, PCM, WAV, WMA |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Bluetooth | No |
Radio
| Specification | Value |
|---|---|
| Supported radio bands | AM, FM |
| Internet radio | Yes |
| Internet radio services supported | vTuner |
Optical drive
| Specification | Value |
|---|---|
| Optical drive included | No |
Video
| Specification | Value |
|---|---|
| Supported graphics resolutions | 1280 x 720 (HD 720), 1920 x 1080 (HD 1080) |
| Supported video modes | 1080i, 1080p, 720p |
| 3D | Yes |
| Video upscaling | Yes |
Technical details
| Specification | Value |
|---|---|
| Audio decoders | Dolby Digital Plus, Dolby Pro Logic IIx, Dolby TrueHD, DTS-HD |
| HDMI version | 1.3 |
| Multi-Zone capability | Yes |
| Multi-Zone quantity | 1 |
| Apple docking compatibility | Not supported |
| Graphical user interface (GUI) | Yes |
| Audio Lip synchronization | Yes |
| Bi-amping | Yes |
| Colour depth | 36 bit |
| Digital Living Network Alliance (DLNA) certified | Yes |
| On Screen Display (OSD) | Yes |
| Product colour | Black |
| Remote control included | Yes |
| Volume control | Rotary |
Power
| Specification | Value |
|---|---|
| Power consumption (standby) | 0.3 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 435 mm |
| Depth | 430 mm |
| Height | 182 mm |
| Weight | 15.1 kg |
Packaging content
| Specification | Value |
|---|---|
| Manual | Yes |
| User guide | Yes |
Other features
| Specification | Value |
|---|---|
| Compatible operating systems | Windows 7 |
| Dimensions (WxDxH) | 435 x 430 x 182 mm |
| HDMI | Yes |
| HDMI ports quantity | 10 |
| Sound enhancement | Yes |
