RX-V500D 5.1 channels Surround 3D Black
Model RX-V500DPart no. RX-V500DBLEAN 4957812531160
38 specifications
- Weight8.1 kg
- ColourBlack
- Audio output channels5.1 channels
- HDMI in5
- Number of HDMI outputs1
- Ethernet LANYes
Overview
- Weight
- 8.1 kg
- Colour
- Black
- Audio output channels
- 5.1 channels
- HDMI in
- 5
- Number of HDMI outputs
- 1
- Ethernet LAN
- Yes
- Brand
- Yamaha
- Category
- AV Receiver
- Model
- RX-V500D
- Part numbers
- RX-V500DBL, RX-V500DTI
- EAN / UPC
- 4957812531160, 4957812531184
- Also known as
- Yamaha RX-V500D 5.1 channels Surround 3D Black
Specifications
38 specifications in 11 groups
Audio
| Specification | Value |
|---|---|
| Audio output channels | 5.1 channels |
| Receiver type | Surround |
| Power output per channel (1KHz@8 Ohm) | 115 W |
| Power output per channel (1KHz@6 Ohm) | 135 W |
| Dynamic power per channel (4 Ohm) | 130 W |
| Total Harmonic Distortion (THD) | 0.9% |
| Audio D/A Converter (DAC) | 24-bit/192kHz |
Inputs
| Specification | Value |
|---|---|
| HDMI in | 5 |
| Component video (YPbPr/YCbCr) in | 2 |
| Composite video in | 5 |
| Audio (L/R) in | 4 |
| Digital audio optical in | 2 |
| Digital audio coaxial in | 2 |
| Ethernet LAN (RJ-45) ports | 1 |
| USB ports quantity | 1 |
Outputs
| Specification | Value |
|---|---|
| Number of HDMI outputs | 1 |
| Component video (YPbPr/YCbCr) out | 1 |
| Composite video out | 1 |
| Audio (L/R) out | 1 |
| Headphone outputs | 1 |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
Radio
| Specification | Value |
|---|---|
| Supported radio bands | AM, DAB, DAB+, FM |
Optical drive
| Specification | Value |
|---|---|
| Optical drive included | No |
Storage
| Specification | Value |
|---|---|
| Card reader integrated | No |
Video
| Specification | Value |
|---|---|
| 3D | Yes |
Technical details
| Specification | Value |
|---|---|
| Display | LED |
| Audio decoders | Dolby Digital Plus, Dolby TrueHD, DTS-HD Master Audio |
| Apple docking compatibility | Not supported |
| AirPlay | Yes |
| On Screen Display (OSD) | Yes |
| Product colour | Black |
| Remote control included | Yes |
| Volume control | Rotary |
Power
| Specification | Value |
|---|---|
| Power consumption (standby) | 0.1 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 435 mm |
| Depth | 315 mm |
| Height | 161 mm |
| Weight | 8.1 kg |
