RX-V473BL AV receiver
80 W 5.1 channels 3D Black
Model RX-V473BL
54 specifications
- Weight8.1 kg
- ColourBlack
- Power output per channel (20-20KHz@8 Ohm)80 W
- HDMI in4
- Number of HDMI outputs1
- Ethernet LANNo
Overview
- Weight
- 8.1 kg
- Colour
- Black
- Power output per channel (20-20KHz@8 Ohm)
- 80 W
- HDMI in
- 4
- Number of HDMI outputs
- 1
- Ethernet LAN
- No
- Brand
- Yamaha
- Category
- AV Receiver
- Model
- RX-V473BL
- Part number
- RX-V473BL
- Also known as
- Yamaha RX-V473BL AV receiver 80 W 5.1 channels 3D Black
Specifications
54 specifications in 9 groups
Audio
| Specification | Value |
|---|---|
| Power output per channel (20-20KHz@8 Ohm) | 80 W |
| Audio output channels | 5.1 channels |
| Power output per channel (1KHz@8 Ohm) | 115 W |
| Power output per channel (1KHz@6 Ohm) | 130 W |
| Dynamic power per channel (4 Ohm) | 160 W |
| Dynamic power per channel (8 Ohm) | 110 W |
| Input sensitivity | 200 mV |
| Output level | 200 mV |
| Total Harmonic Distortion (THD) | 0.9% |
| Input impedance | 47 Ω |
| Output impedance | 1200 Ω |
| Audio D/A Converter (DAC) | 24-bit/192kHz |
| Impedance | 8 Ω |
| Maximum input level | 2.3 V |
| Signal-to-Noise Ratio (SNR) | 100 dB |
Inputs
| Specification | Value |
|---|---|
| HDMI in | 4 |
| Component video (YPbPr/YCbCr) in | 2 |
| Composite video in | 5 |
| Audio (L/R) in | 4 |
| Digital audio optical in | 2 |
| Digital audio coaxial in | 2 |
| USB ports quantity | 1 |
Outputs
| Specification | Value |
|---|---|
| Number of HDMI outputs | 1 |
| Component video (YPbPr/YCbCr) out | 1 |
| Composite video out | 1 |
| Audio (L/R) out | 1 |
| Headphone outputs | 1 |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | No |
| Wi-Fi | No |
| Bluetooth | No |
Radio
| Specification | Value |
|---|---|
| Supported radio bands | AM, FM |
| Internet radio | Yes |
| Internet radio services supported | vTuner |
| AM band range | 530 - 1710 kHz |
| FM band range | 87.5 - 107.9 MHz |
Video
| Specification | Value |
|---|---|
| 3D | Yes |
Technical details
| Specification | Value |
|---|---|
| Audio decoders | Dolby Digital Plus, Dolby TrueHD, DTS-HD Master Audio |
| Deep colour support | Yes |
| x.v.Color support | Yes |
| Audio Return Channel (ARC) | Yes |
| Apple docking compatibility | Not supported |
| AV input | Yes |
| AV output | Yes |
| AirPlay | Yes |
| Digital Living Network Alliance (DLNA) certified | Yes |
| On Screen Display (OSD) | Yes |
| Product colour | Black |
| Remote control included | Yes |
| Volume control | Rotary |
Power
| Specification | Value |
|---|---|
| Power consumption (standby) | 0.1 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 435 mm |
| Depth | 315 mm |
| Height | 161 mm |
| Weight | 8.1 kg |
