Yamaha RX-A2030 140 W 9.2 channels 3D Black: Full Specifications

Overview

Weight: 17.1 kg
Colour: Black
Power output per channel (20-20KHz@8 Ohm): 140 W
HDMI in: 8
Number of HDMI outputs: 2
12V trigger: Yes

Brand: Yamaha
Category: AV Receiver
Model: RX-A2030
Part number: RX-A2030B
EAN / UPC: 4957812535212
Also known as: Yamaha RX-A2030 140 W 9.2 channels 3D Black

Specifications

56 specifications in 12 groups

Audio

Specification	Value
Power output per channel (20-20KHz@8 Ohm)	140 W
Audio output channels	9.2 channels
Dynamic power per channel (4 Ohm)	285 W
Dynamic power per channel (8 Ohm)	165 W
Audio D/A Converter (DAC)	24-bit/192kHz
Pre-out channels	7.2
Pre-out connectivity	Yes

Inputs

Specification	Value
HDMI in	8
Component video (YPbPr/YCbCr) in	4
Composite video in	5
S-Video inputs quantity	4
Audio (L/R) in	10
Digital audio optical in	4
Digital audio coaxial in	3
Remote (IR) input	2
USB ports quantity	1

Outputs

Specification	Value
Number of HDMI outputs	2
Component video (YPbPr/YCbCr) out	1
Composite video out	1
S-Video outputs quantity	1
Digital audio optical out	1
Digital audio coaxial out	0
Remote (IR) output	2
Headphone outputs	1
Headphone connectivity	6.3 mm

Ports & interfaces

Specification	Value
12V trigger	Yes

Network

Specification	Value
Ethernet LAN	Yes

Radio

Specification	Value
Supported radio bands	AM, FM
AM band range	522 - 1.620 kHz
FM band range	87.5 - 108 MHz

Storage

Specification	Value
Card reader integrated	No

Video

Specification	Value
3D	Yes
Video upscaling	Yes

Technical details

Specification	Value
Display	LED
Audio decoders	Dolby Digital Plus, Dolby Pro Logic IIx, Dolby TrueHD, DTS-HD Master Audio
Deep colour support	Yes
x.v.Color support	Yes
Audio Return Channel (ARC)	Yes
Mobile High-Definition Link (MHL)	Yes
Apple docking compatibility	Not supported
AV input	Yes
AirPlay	Yes
On Screen Display (OSD)	Yes
Product colour	Black
RS-232 interface	Yes
Remote control included	Yes

Power

Specification	Value
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.35 W

Weight & dimensions

Specification	Value
Width	435 mm
Depth	467 mm
Height	192 mm
Weight	17.1 kg

Packaging content

Specification	Value
Manual	Yes
User guide	Yes
Warranty card	Yes
