Yamaha RX-A1040T AV receiver: Full Specifications

Overview

Weight: 14.9 kg
Colour: Titanium
Power output per channel (20-20KHz@8 Ohm): 110 W
HDMI in: 8
Number of HDMI outputs: 2
12V trigger: Yes

Brand: Yamaha
Category: AV Receiver
Model: RX-A1040T
Part number: RX-A1040T
EAN / UPC: 4957812558648
Also known as: Yamaha RX-A1040T AV receiver 110 W 7.2 channels Surround 3D Titanium

Specifications

54 specifications in 11 groups

Audio

Specification	Value
Power output per channel (20-20KHz@8 Ohm)	110 W
Audio output channels	7.2 channels
Receiver type	Surround
Power output per channel (1KHz@8 Ohm)	165 W
Dynamic power per channel (4 Ohm)	210 W
Dynamic power per channel (8 Ohm)	135 W
Total Harmonic Distortion (THD)	0.06%
Audio A/D Converter (ADC)	24-bit/96kHz
Audio D/A Converter (DAC)	24-bit/192kHz

Inputs

Specification	Value
HDMI in	8
Component video (YPbPr/YCbCr) in	3
Composite video in	5
Digital audio optical in	3
Digital audio coaxial in	3
Remote (IR) input	1
Ethernet LAN (RJ-45) ports	1
USB ports quantity	1

Outputs

Specification	Value
Number of HDMI outputs	2
Component video (YPbPr/YCbCr) out	1
Composite video out	2
Remote (IR) output	1
Headphone outputs	1

Ports & interfaces

Specification	Value
12V trigger	Yes
12V trigger ports quantity	2
Phono inputs (RCA)	1

File formats

Specification	Value
Audio formats supported	FLAC, M4A, WAV

Network

Specification	Value
Ethernet LAN	Yes
Wi-Fi	Yes

Radio

Specification	Value
Supported radio bands	AM, FM

Video

Specification	Value
3D	Yes
Video upscaling	Yes

Technical details

Specification	Value
Audio decoders	Dolby Digital Plus, Dolby Pro Logic IIx, Dolby TrueHD, DTS-HD Master Audio
Deep colour support	Yes
x.v.Color support	Yes
Equalizer	Yes
Audio Return Channel (ARC)	Yes
Mobile High-Definition Link (MHL)	Yes
Apple docking compatibility	Not supported
Digital Signal Processing (DSP)	Yes
AirPlay	Yes
Audio Lip synchronization	Yes
Audio input	10
Bi-amping	Yes
On Screen Display (OSD)	Yes
Product colour	Titanium
Remote control included	Yes
Volume control	Rotary
Audio output - analog	1
RS-232C for control	Yes

Power

Specification	Value
Power consumption (standby)	0.1 W

Weight & dimensions

Specification	Value
Width	435 mm
Depth	432 mm
Height	182 mm
Weight	14.9 kg
