RX-A1030 7.2 channels 3D Black
Model RX-A1030Part no. RX-A1030BKEAN 4957812534994
41 specifications
- Weight15.1 kg
- ColourBlack
- Audio output channels7.2 channels
- HDMI in2
- Number of HDMI outputs8
- Ethernet LANNo
Overview
- Weight
- 15.1 kg
- Colour
- Black
- Audio output channels
- 7.2 channels
- HDMI in
- 2
- Number of HDMI outputs
- 8
- Ethernet LAN
- No
- Brand
- Yamaha
- Category
- AV Receiver
- Model
- RX-A1030
- Part numbers
- RX-A1030BK, RX-A1030TIT
- EAN / UPC
- 4957812534994, 4957812535052
- Also known as
- Yamaha RX-A1030 7.2 channels 3D Black
Specifications
41 specifications in 11 groups
Audio
| Specification | Value |
|---|---|
| Audio output channels | 7.2 channels |
| Power output per channel (1KHz@8 Ohm) | 165 W |
| Dynamic power per channel (4 Ohm) | 210 W |
| Dynamic power per channel (8 Ohm) | 135 W |
| Audio D/A Converter (DAC) | 24-bit/192kHz |
| Pre-out channels | 7.2 |
Inputs
| Specification | Value |
|---|---|
| HDMI in | 2 |
| Component video (YPbPr/YCbCr) in | 4 |
| Composite video in | 5 |
| S-Video inputs quantity | 4 |
| Audio (L/R) in | 10 |
| Digital audio optical in | 4 |
| Digital audio coaxial in | 3 |
| Remote (IR) input | 1 |
Outputs
| Specification | Value |
|---|---|
| Number of HDMI outputs | 8 |
| Component video (YPbPr/YCbCr) out | 1 |
| Composite video out | 1 |
| S-Video outputs quantity | 1 |
| Audio (L/R) out | 1 |
| Digital audio optical out | 1 |
| Digital audio coaxial out | 0 |
| Remote (IR) output | 1 |
| Headphone outputs | 1 |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | No |
| Wi-Fi | No |
Radio
| Specification | Value |
|---|---|
| Supported radio bands | AM, FM |
Optical drive
| Specification | Value |
|---|---|
| Optical drive included | No |
Storage
| Specification | Value |
|---|---|
| Card reader integrated | No |
Video
| Specification | Value |
|---|---|
| 3D | Yes |
| Video upscaling | Yes |
Technical details
| Specification | Value |
|---|---|
| Audio decoders | Dolby Digital Plus, Dolby Pro Logic IIx, Dolby TrueHD, DTS-HD Master Audio |
| Apple docking compatibility | Not supported |
| AirPlay | Yes |
| On Screen Display (OSD) | Yes |
| Product colour | Black |
| Remote control included | Yes |
Power
| Specification | Value |
|---|---|
| Power consumption (standby) | 0.3 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 235 mm |
| Depth | 432 mm |
| Height | 182 mm |
| Weight | 15.1 kg |
