R-N500 80 W 2.0 channels stereo Black
Model R-N500Part no. R-N500-BEAN 4957812542968
46 specifications
- ConnectivityWired
- Weight9.8 kg
- ColourBlack
- Power output per channel (20-20KHz@8 Ohm)80 W
- HDMI in0
- Line-outYes
Overview
- Connectivity
- Wired
- Weight
- 9.8 kg
- Colour
- Black
- Power output per channel (20-20KHz@8 Ohm)
- 80 W
- HDMI in
- 0
- Line-out
- Yes
- Brand
- Yamaha
- Category
- AV Receiver
- Model
- R-N500
- Part numbers
- R-N500-B, R-N500-S
- EAN / UPC
- 4957812542968, 4957812542975, 4957812542913
- Also known as
- Yamaha R-N500 80 W 2.0 channels stereo Black
Specifications
46 specifications in 12 groups
Audio
| Specification | Value |
|---|---|
| Power output per channel (20-20KHz@8 Ohm) | 80 W |
| Audio output channels | 2.0 channels |
| Receiver type | stereo |
| Power output per channel (1KHz@8 Ohm) | 115 W |
| Dynamic power per channel (4 Ohm) | 150 W |
| Dynamic power per channel (8 Ohm) | 105 W |
| Total Harmonic Distortion (THD) | 0.015% |
Inputs
| Specification | Value |
|---|---|
| HDMI in | 0 |
| Digital audio optical in | 2 |
| Digital audio coaxial in | 2 |
| Ethernet LAN (RJ-45) ports | 1 |
| Remote control in | 1 |
| USB ports quantity | 1 |
Outputs
| Specification | Value |
|---|---|
| Line-out | Yes |
| Remote control out | 1 |
Ports & interfaces
| Specification | Value |
|---|---|
| Speakers connectivity type | RCA |
| Connectivity technology | Wired |
| AM antenna ports quantity | 1 |
| FM antenna ports quantity | 1 |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
Radio
| Specification | Value |
|---|---|
| Supported radio bands | AM, FM |
| Internet radio | Yes |
| Radio Data System (RDS) | Yes |
| AM band range | 530 - 1710 kHz |
| FM band range | 87.5 - 107.9 MHz |
| Preset stations quantity | 40 |
Optical drive
| Specification | Value |
|---|---|
| Optical drive included | No |
Storage
| Specification | Value |
|---|---|
| Card reader integrated | No |
Technical details
| Specification | Value |
|---|---|
| Apple docking compatibility | Not supported |
| Bass adjustment | Yes |
| Treble adjustment | Yes |
| AirPlay | Yes |
| Bi-amping | Yes |
| Digital Living Network Alliance (DLNA) certified | Yes |
| Product colour | Black |
| Remote control included | Yes |
| TV tuner integrated | No |
| Volume control | Rotary |
Power
| Specification | Value |
|---|---|
| Power consumption (standby) | 0.1 W |
| Power consumption (typical) | 190 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 435 mm |
| Depth | 387 mm |
| Height | 151 mm |
| Weight | 9.8 kg |
Packaging content
| Specification | Value |
|---|---|
| AM antenna | Yes |
| FM antenna | Yes |
