R-N303 Black
Model R-N303Part no. R-N303 BLACKEAN 4957812620307
36 specifications
- Weight7.21 kg
- ColourBlack
- Power output per channel (1KHz@8 Ohm)140 W
- Audio (L/R) in6
- Audio (L/R) out1
- Video formats supportedMPEG4
Overview
- Weight
- 7.21 kg
- Colour
- Black
- Power output per channel (1KHz@8 Ohm)
- 140 W
- Audio (L/R) in
- 6
- Audio (L/R) out
- 1
- Video formats supported
- MPEG4
- Brand
- Yamaha
- Category
- AV Receiver
- Model
- R-N303
- Part numbers
- R-N303 BLACK, R-N303 SILVER
- EAN / UPC
- 4957812620307, 4957812620338
- Also known as
- Yamaha R-N303 Black
Specifications
36 specifications in 11 groups
Audio
| Specification | Value |
|---|---|
| Power output per channel (1KHz@8 Ohm) | 140 W |
| Dynamic power per channel (2 Ohm) | 180 W |
| Dynamic power per channel (4 Ohm) | 115 W |
| Dynamic power per channel (6 Ohm) | 150 W |
| Dynamic power per channel (8 Ohm) | 125 W |
| Input sensitivity | 500 mV |
| Total Harmonic Distortion (THD) | 10% |
| Frequency range | 40 - 20000 Hz |
| Impedance | 8 Ω |
| RMS rated power | 100 W |
| Signal-to-Noise Ratio (SNR) | 65 dB |
Inputs
| Specification | Value |
|---|---|
| Audio (L/R) in | 6 |
| Digital audio optical in | 1 |
| Digital audio coaxial in | 1 |
Outputs
| Specification | Value |
|---|---|
| Audio (L/R) out | 1 |
| Headphone outputs | 1 |
File formats
| Specification | Value |
|---|---|
| Audio formats supported | AIFF, ALAC, DSD, FLAC, MP3, MP3 VBR, WAV, Wave, WMA, WMA-L, WMA-PRO |
| Video formats supported | MPEG4 |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| Bluetooth | Yes |
| Wi-Fi ready | Yes |
Radio
| Specification | Value |
|---|---|
| Supported radio bands | FM |
Video
| Specification | Value |
|---|---|
| 3D | No |
Technical details
| Specification | Value |
|---|---|
| AirPlay | Yes |
| Digital Living Network Alliance (DLNA) certified | Yes |
| Headphone out | Yes |
| Product colour | Black |
Power
| Specification | Value |
|---|---|
| Power consumption (standby) | 0.1 W |
| Power consumption (typical) | 1.8 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 431.8 mm |
| Depth | 330.2 mm |
| Height | 127 mm |
| Weight | 7.21 kg |
Packaging content
| Specification | Value |
|---|---|
| FM antenna | Yes |
| Manual | Yes |
