MusicCast RX-A1060
Model MusicCast RX-A1060Part no. RX-A1060BLEAN 4957812601641
56 specifications
- ConnectivityWired & Wireless
- Weight14.9 kg
- ColourBlack
- Power output per channel (20-20KHz@8 Ohm)110 W
- HDMI in8
- Number of HDMI outputs2
Overview
- Connectivity
- Wired & Wireless
- Weight
- 14.9 kg
- Colour
- Black
- Power output per channel (20-20KHz@8 Ohm)
- 110 W
- HDMI in
- 8
- Number of HDMI outputs
- 2
- Brand
- Yamaha
- Category
- AV Receiver
- Model
- MusicCast RX-A1060
- Part numbers
- RX-A1060BL, RX-A1060T
- EAN / UPC
- 4957812601641, 4957812601702
- Also known as
- Yamaha MusicCast RX-A1060 110 W 7.2 channels stereo 3D Black
Specifications
56 specifications in 12 groups
Audio
| Specification | Value |
|---|---|
| Power output per channel (20-20KHz@8 Ohm) | 110 W |
| Audio output channels | 7.2 channels |
| Receiver type | stereo |
| Dynamic power per channel (4 Ohm) | 210 W |
| Dynamic power per channel (8 Ohm) | 135 W |
| Audio D/A Converter (DAC) | 24-bit/192kHz |
| Pre-out channels | 7.2 |
| Pre-out connectivity | Yes |
Inputs
| Specification | Value |
|---|---|
| HDMI in | 8 |
| Component video (YPbPr/YCbCr) in | 3 |
| Composite video in | 5 |
| Audio (L/R) in | 9 |
| Digital audio optical in | 3 |
| Digital audio coaxial in | 3 |
| Remote (IR) input | 1 |
Outputs
| Specification | Value |
|---|---|
| Number of HDMI outputs | 2 |
| Component video (YPbPr/YCbCr) out | 1 |
| Composite video out | 1 |
| Digital audio optical out | 0 |
| Digital audio coaxial out | 0 |
| Remote (IR) output | 1 |
| Headphone outputs | 1 |
| Headphone connectivity | 3.5 mm |
Ports & interfaces
| Specification | Value |
|---|---|
| Speakers connectivity type | 3.5mm |
| Connectivity technology | Wired & Wireless |
| 12V trigger | Yes |
| 12V trigger ports quantity | 2 |
| Phono inputs (RCA) | 1 |
| RS-232 ports | 1 |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| Bluetooth | Yes |
Radio
| Specification | Value |
|---|---|
| Supported radio bands | AM, FM |
Optical drive
| Specification | Value |
|---|---|
| Optical drive included | No |
Storage
| Specification | Value |
|---|---|
| Card reader integrated | No |
Video
| Specification | Value |
|---|---|
| Supported graphics resolutions | 4096 x 2160 |
| 3D | Yes |
| Video D/A Converter (DAC) | 24-bit/192kHz |
Technical details
| Specification | Value |
|---|---|
| Display | LCD |
| Audio decoders | DTS, DTS-HD Master Audio, Dolby Digital Plus, Dolby Pro Logic IIx, Dolby TrueHD |
| x.v.Color support | Yes |
| Apple docking | Yes |
| Apple docking compatibility | Yes |
| Graphical user interface (GUI) | Yes |
| Digital Signal Processing (DSP) | Yes |
| AirPlay | Yes |
| Auto standby | Yes |
| Number of products included | 1 pc(s) |
| Product colour | Black |
| RS-232 interface | Yes |
| Remote control included | Yes |
Power
| Specification | Value |
|---|---|
| Power consumption (standby) | 0.1 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 435 mm |
| Depth | 439 mm |
| Height | 182 mm |
| Weight | 14.9 kg |
