HTR-4065 80 W 5.1 channels 3D Black
Model HTR-4065Part no. HTR-4065BL
43 specifications
- ConnectivityWired
- Weight8.1 kg
- ColourBlack
- Power output per channel (20-20KHz@8 Ohm)80 W
- HDMI in4
- Number of HDMI outputs1
Overview
- Connectivity
- Wired
- Weight
- 8.1 kg
- Colour
- Black
- Power output per channel (20-20KHz@8 Ohm)
- 80 W
- HDMI in
- 4
- Number of HDMI outputs
- 1
- Brand
- Yamaha
- Category
- AV Receiver
- Model
- HTR-4065
- Part numbers
- HTR-4065BL, HTR-4065
- Also known as
- Yamaha HTR-4065 80 W 5.1 channels 3D Black
Specifications
43 specifications in 13 groups
Audio
| Specification | Value |
|---|---|
| Power output per channel (20-20KHz@8 Ohm) | 80 W |
| Audio output channels | 5.1 channels |
| Power output per channel (1KHz@8 Ohm) | 115 W |
| Dynamic power per channel (4 Ohm) | 160 W |
| Dynamic power per channel (8 Ohm) | 110 W |
| Pre-out connectivity | Yes |
Inputs
| Specification | Value |
|---|---|
| HDMI in | 4 |
| Component video (YPbPr/YCbCr) in | 2 |
| Composite video in | 5 |
| Audio (L/R) in | 4 |
| Digital audio optical in | 2 |
| Digital audio coaxial in | 2 |
| Ethernet LAN (RJ-45) ports | 1 |
| USB ports quantity | 1 |
Outputs
| Specification | Value |
|---|---|
| Number of HDMI outputs | 1 |
| Component video (YPbPr/YCbCr) out | 1 |
| Composite video out | 1 |
| Audio (L/R) out | 1 |
| Headphone outputs | 1 |
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | No |
| Wi-Fi | No |
Radio
| Specification | Value |
|---|---|
| Supported radio bands | AM, FM |
Optical drive
| Specification | Value |
|---|---|
| Optical drive included | No |
Storage
| Specification | Value |
|---|---|
| Card reader integrated | No |
Video
| Specification | Value |
|---|---|
| 3D | Yes |
| Video D/A Converter (DAC) | 24-bit/192kHz |
Technical details
| Specification | Value |
|---|---|
| Audio decoders | Dolby Digital Plus, Dolby TrueHD, DTS-HD Master Audio |
| Deep colour support | Yes |
| x.v.Color support | Yes |
| Apple docking compatibility | Not supported |
| Digital Living Network Alliance (DLNA) certified | Yes |
| On Screen Display (OSD) | Yes |
| Product colour | Black |
| Remote control included | Yes |
| USB 2.0 ports quantity | 1 |
Power
| Specification | Value |
|---|---|
| Power consumption (standby) | 0.1 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 435 mm |
| Depth | 315 mm |
| Height | 161 mm |
| Weight | 8.1 kg |
Packaging content
| Specification | Value |
|---|---|
| Batteries included | Yes |
| Manual | Yes |
