HTR-2866 70 W 5.1 channels Surround Black
Model HTR-2866Part no. AHTR2866BLEAN 4957812529037
30 specifications
- Weight7.4 kg
- ColourBlack
- Power output per channel (20-20KHz@8 Ohm)70 W
- HDMI in4
- Number of HDMI outputs1
- Speakers connectivity typeClamp terminals
Overview
- Weight
- 7.4 kg
- Colour
- Black
- Power output per channel (20-20KHz@8 Ohm)
- 70 W
- HDMI in
- 4
- Number of HDMI outputs
- 1
- Speakers connectivity type
- Clamp terminals
- Brand
- Yamaha
- Category
- AV Receiver
- Model
- HTR-2866
- Part number
- AHTR2866BL
- EAN / UPC
- 4957812529037
- Also known as
- Yamaha HTR-2866 70 W 5.1 channels Surround Black
Specifications
30 specifications in 11 groups
Audio
| Specification | Value |
|---|---|
| Power output per channel (20-20KHz@8 Ohm) | 70 W |
| Audio output channels | 5.1 channels |
| Receiver type | Surround |
| Power output per channel (1KHz@6 Ohm) | 100 W |
| Dynamic power per channel (4 Ohm) | 130 W |
| Audio D/A Converter (DAC) | 24-bit/192kHz |
Inputs
| Specification | Value |
|---|---|
| HDMI in | 4 |
| Component video (YPbPr/YCbCr) in | 2 |
| Composite video in | 4 |
| Digital audio optical in | 2 |
| Digital audio coaxial in | 2 |
Outputs
| Specification | Value |
|---|---|
| Number of HDMI outputs | 1 |
| Component video (YPbPr/YCbCr) out | 1 |
| Composite video out | 1 |
| Headphone outputs | 1 |
Ports & interfaces
| Specification | Value |
|---|---|
| Speakers connectivity type | Clamp terminals |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | No |
| Wi-Fi | No |
Radio
| Specification | Value |
|---|---|
| Supported radio bands | AM, FM |
Optical drive
| Specification | Value |
|---|---|
| Optical drive included | No |
Storage
| Specification | Value |
|---|---|
| Card reader integrated | No |
Technical details
| Specification | Value |
|---|---|
| Audio decoders | Dolby Digital Plus, Dolby TrueHD, DTS-HD Master Audio |
| Digital Signal Processing (DSP) | Yes |
| Product colour | Black |
| Remote control included | Yes |
Power
| Specification | Value |
|---|---|
| Power consumption (standby) | 0.3 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 435 mm |
| Depth | 315 mm |
| Height | 151 mm |
| Weight | 7.4 kg |
