999-82600-000
Model 999-82600-000EAN 840077508104
26 specifications
- ColourBlack
- Maximum resolution1920 x 1080 pixels
- Ethernet LANYes
- HDMI ports quantity2
- Power source typeDC
- Operating temperature (T-T)0 - 40 °C
Overview
- Colour
- Black
- Maximum resolution
- 1920 x 1080 pixels
- Ethernet LAN
- Yes
- HDMI ports quantity
- 2
- Power source type
- DC
- Operating temperature (T-T)
- 0 - 40 °C
- Brand
- Vaddio
- Category
- AV Conferencing Bridge
- Model
- 999-82600-000
- Part number
- 999-82600-000
- EAN / UPC
- 840077508104
- Also known as
- Vaddio AV Bridge Nano
Specifications
26 specifications in 9 groups
Video
| Specification | Value |
|---|---|
| Maximum resolution | 1920 x 1080 pixels |
| Supported graphics resolutions | 640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 768 (WXGA), 1280 x 800 (WXGA), 1366 x 768, 1600 x 900 |
| Supported video modes | 1080p |
| Frame rate | 60 fps |
| Video formats supported | H.264 |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet interface type | Gigabit Ethernet |
Features
| Specification | Value |
|---|---|
| Product colour | Black |
| Certification | CE,FCC,TAA |
Ports & interfaces
| Specification | Value |
|---|---|
| HDMI ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| Audio input | 1 |
| Audio output | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
Power
| Specification | Value |
|---|---|
| Power source type | DC |
| DC input voltage | 12 V |
| Input current | 1 A |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 20 - 80% |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | Federal Communications Commission (FCC), CE, TAA |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 148.1 mm |
| Depth | 112.5 mm |
| Height | 32.3 mm |
| Package weight | 1.36 kg |
Packaging content
| Specification | Value |
|---|---|
| Cables included | DC, Power, USB |
| Quick start guide | Yes |
