TP-Link Archer NX505 5G AX3000 Wireless Dual-Band Gigabit

Archer NX505 5G AX3000 Wireless Dual-Band Gigabit

Model Archer NX505 5G AX3000 Wireless Dual-Band GigabitPart no. ARCHER NX505EAN 1210002610292

78 specifications

SpeedWi-Fi 6 (802.11ax)
TypeDesktop/pole router
Weight610 g
ColourWhite
Ethernet WANYes
Wi-Fi bandDual-band (2.4 GHz / 5 GHz)

See all specifications

Overview

Speed: Wi-Fi 6 (802.11ax)
Type: Desktop/pole router
Weight: 610 g
Colour: White
Ethernet WAN: Yes
Wi-Fi band: Dual-band (2.4 GHz / 5 GHz)

Brand: TP-Link
Category: Wireless Router
Model: Archer NX505 5G AX3000 Wireless Dual-Band Gigabit
Part number: ARCHER NX505
EAN / UPC: 1210002610292, 1210002610315
Also known as: TP-Link Archer NX505 5G AX3000 Wireless Dual-Band Gigabit wireless router Gigabit Ethernet Dual-band (2.4 GHz / 5 GHz) White

Specifications

78 specifications in 18 groups

WAN connection

Specification	Value
Ethernet WAN	Yes
DSL WAN	No
SIM card slot	Yes
WAN connection type	RJ-45

Wireless LAN features

Specification	Value
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
WLAN data transfer rate (max)	3000 Mbit/s
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
WLAN data transfer rate (first band)	574 Mbit/s
WLAN data transfer rate (second band)	2402 Mbit/s

Network

Specification	Value
Ethernet LAN	Yes
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN data rates	10,100,1000 Mbit/s
Cabling technology	10/100/1000Base-T(X)
Port forwarding	Yes
Port triggering	Yes
Dynamic DNS (DDNS)	Yes
Number of guest networks (2.4 GHz)	1
Number of guest networks (5 GHz)	1

Mobile network

Specification	Value
Mobile network generation	5G
3G standards	DC-HSDPA, HSPA, HSPA+, UMTS
4G standard	LTE-TDD & LTE-FDD
5G bands supported	700,800,850,900,1800,2100,2300,2500,2600,3500,3700 MHz
3G bands supported	850,900,2100 MHz
4G bands supported	700,800,850,900,1800,2100,2300,2500,2600,3500,3700 MHz
SIM card type	NanoSIM

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	2
USB port	No

Management features

Specification	Value
Wi-Fi Multimedia (WMM)/(WME)	Yes
Quality of Service (QoS) support	Yes
Reset button	Yes
WPS push button	Yes

Security

Specification	Value
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Guest access	Yes
DoS attack prevention	Yes
Parental control	Yes
Filtering	Yes
IP address filtering	Yes
URL filtering	Yes
DMZ support	Yes

Protocols

Specification	Value
DHCP client	Yes
DHCP server	Yes
Universal Plug and Play (UPnP)	Yes
Supported network protocols	IPv4, IPv6

Design

Specification	Value
Product type	Desktop/pole router
Product colour	White
Built-in display	No

Packaging content

Specification	Value
Cables included	LAN (RJ-45)
AC adapter included	Yes
Quick installation guide	Yes

Certificates

Specification	Value
Compliance certificates	CE, RoHS

Antenna

Specification	Value
Antenna design	Internal & external
Antenna connector type	SMA

Power

Specification	Value
Power source type	AC
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Output voltage	12 V
Output current	2 A

Operational conditions

Specification	Value
Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90%
Storage temperature (T-T)	-40 - 70 °C

System requirements

Specification	Value
Windows operating systems supported	Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 2000, Windows 2000 Professional, Windows 7, Windows 7 Enterp
Linux operating systems supported	Yes
Mac operating systems supported	Yes
Mac compatibility	Yes

Weight & dimensions

Specification	Value
Depth	190 mm
Height	99 mm
Weight	610 g
Width	99 mm

Packaging data

Specification	Value
Package width	230 mm
Package depth	115 mm
Package height	221 mm
Package weight	1.27 kg
Package type	Box
Number of products included	1 pc(s)

Logistics data

Specification	Value
Customs product code (TARIC)	8517620000
Country of origin	China
