Router Giga MESH AC1200MESH AC1200 MU-MIMO Gigabit Router USB
Model Router Giga MESH AC1200MESH AC1200 MU-MIMO Gigabit Router USBPart no. DIR-825M
43 specifications
- SpeedWi-Fi 5 (802.11ac)
- TypePortable router
- ColourBlack
- Ethernet WANYes
- Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
- Mobile network generationNot supported
Overview
- Speed
- Wi-Fi 5 (802.11ac)
- Type
- Portable router
- Colour
- Black
- Ethernet WAN
- Yes
- Wi-Fi band
- Dual-band (2.4 GHz / 5 GHz)
- Mobile network generation
- Not supported
- Brand
- D-Link
- Category
- Wireless Router
- Model
- Router Giga MESH AC1200MESH AC1200 MU-MIMO Gigabit Router USB
- Part number
- DIR-825M
- Also known as
- D-Link Router Giga MESH AC1200MESH AC1200 MU-MIMO Gigabit Router USB wireless router Gigabit Ethernet Dual-band (2.4 GHz / 5 GHz) Black
Specifications
43 specifications in 15 groups
WAN connection
| Specification | Value |
|---|---|
| Ethernet WAN | Yes |
Wireless LAN features
| Specification | Value |
|---|---|
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| WLAN data transfer rate (max) | 867 Mbit/s |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Modulation | OFDM, DSSS |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN interface type | Gigabit Ethernet |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3u |
| VPN Passthrough | Yes |
Mobile network
| Specification | Value |
|---|---|
| Mobile network generation | Not supported |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 5 |
| USB port | Yes |
| USB 2.0 ports quantity | 1 |
Management features
| Specification | Value |
|---|---|
| Reset button | Yes |
| WPS push button | Yes |
Security
| Specification | Value |
|---|---|
| MAC address filtering | Yes |
| IP address filtering | Yes |
| URL filtering | Yes |
| DMZ support | Yes |
| Network address translation (NAT) | Yes |
Protocols
| Specification | Value |
|---|---|
| DHCP client | Yes |
| DHCP server | Yes |
Design
| Specification | Value |
|---|---|
| Product type | Portable router |
| Product colour | Black |
Packaging content
| Specification | Value |
|---|---|
| Antenna included | Yes |
Antenna
| Specification | Value |
|---|---|
| Antenna design | External |
| Antenna gain level (max) | 5 dBi |
| Antennas quantity | 4 |
Features
| Specification | Value |
|---|---|
| Built-in processor | Yes |
| Processor frequency | 1024 MHz |
| Firmware upgradeable | Yes |
Power
| Specification | Value |
|---|---|
| Power source type | DC |
| Output voltage | 12 V |
| Output current | 1 A |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 5 - 95% |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage relative humidity (H-H) | 5 - 95% |
| Storage temperature (T-T) | -20 - 90 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Depth | 197 mm |
| Height | 44.3 mm |
| Width | 133.9 mm |
