Techly IDATA VGA-VS404
Model IDATA VGA-VS404EAN 8051128100419
29 specifications
- Weight935 g
- ColourBlack
- Video ports quantity8
- AC input voltage5 V
- Dimensions (WxDxH)267 x 115 x 45 mm
- Operating temperature (T-T)0 - 70 °C
Overview
- Weight
- 935 g
- Colour
- Black
- Video ports quantity
- 8
- AC input voltage
- 5 V
- Dimensions (WxDxH)
- 267 x 115 x 45 mm
- Operating temperature (T-T)
- 0 - 70 °C
- Brand
- Techly
- Category
- Video Splitter
- Model
- IDATA VGA-VS404
- Part number
- IDATA VGA-VS404
- EAN / UPC
- 8051128100419
- Also known as
- Techly IDATA VGA-VS404 video splitter 4x VGA
Specifications
29 specifications in 6 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Video ports quantity | 8 |
| Video port type | VGA |
| Video out | 4x VGA |
| Audio ports quantity | 9 |
| Serial ports quantity | 1 |
| DC-in jack | Yes |
Features
| Specification | Value |
|---|---|
| Product colour | Black |
| Maximum resolution | 1920 x 1200 pixels |
| Full HD | Yes |
| 3D | No |
| Vertical scan range | 30 - 170 Hz |
| Maximum refresh rate | 60 Hz |
| Bandwidth | 500 MHz |
| HDCP | No |
| Supported graphics resolutions | 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA) |
| Supported video modes | 1080p |
| Certification | FCC , CE, UL |
Power
| Specification | Value |
|---|---|
| AC input voltage | 5 V |
| Output voltage | 5 V |
| Output current | 2 A |
| Power consumption (typical) | 5 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Dimensions (WxDxH) | 267 x 115 x 45 mm |
| Weight | 935 g |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Manual | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 70 °C |
| Storage temperature (T-T) | -10 - 80 °C |
| Operating relative humidity (H-H) | 10 - 85% |
| Storage relative humidity (H-H) | 5 - 90% |
