10 Port 4K HDMI Splitter
Model VS0110HAPart no. VS0110HA-AT-GEAN 672792009457
42 specifications
- Weight2.32 kg
- ColourBlack
- Video ports quantity11
- AC input voltage5 V
- Width157.8 mm
- Operating temperature (T-T)0 - 40 °C
Overview
- Weight
- 2.32 kg
- Colour
- Black
- Video ports quantity
- 11
- AC input voltage
- 5 V
- Width
- 157.8 mm
- Operating temperature (T-T)
- 0 - 40 °C
- Brand
- ATEN
- Category
- Video Splitter
- Model
- VS0110HA
- Part numbers
- VS0110HA-AT-G, VS0110HA-AT-U, VS0110HA, VS0110HA-AT-E
- EAN / UPC
- 672792009457, 4719264647499
- Also known as
- ATEN 10 Port 4K HDMI Splitter
Specifications
42 specifications in 9 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Video ports quantity | 11 |
| Video port type | HDMI |
| Video out | 10x HDMI |
| HDMI version | 1.4 |
| Serial ports quantity | 1 |
| DC-in jack | Yes |
Features
| Specification | Value |
|---|---|
| Product colour | Black |
| Housing material | Metal |
| Maximum resolution | 4096 x 2160 pixels |
| HD type | 4K Ultra HD |
| 3D | Yes |
| Maximum operating distance | 15 m |
| Bandwidth | 340 MHz |
| HDCP version | 1.4 |
| Rack mounting | Yes |
| HDCP | Yes |
| LED indicators | Link, Power |
| Plug and Play | Yes |
| Certification | FCC, CE |
Power
| Specification | Value |
|---|---|
| AC input voltage | 5 V |
| Power consumption (typical) | 4.34 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 157.8 mm |
| Depth | 437.2 mm |
| Height | 44 mm |
| Weight | 2.32 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 116 mm |
| Package depth | 540 mm |
| Package height | 233 mm |
| Package weight | 2.81 kg |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Manual | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85176990 |
| Master (outer) case net weight | 6.96 kg |
| Master (outer) case width | 375 mm |
| Master (outer) case length | 565 mm |
| Master (outer) case height | 258 mm |
| Master (outer) case gross weight | 9.21 kg |
| Products per master (outer) case | 3 pc(s) |
