IDATA HDMI-H44E
Model IDATA HDMI-H44EEAN 8051128101751
26 specifications
- Weight2.22 kg
- ColourBlack
- Video ports quantity8
- Ethernet LANYes
- AC input voltage5 V
- Dimensions (WxDxH)441 x 202 x 45 mm
Overview
- Weight
- 2.22 kg
- Colour
- Black
- Video ports quantity
- 8
- Ethernet LAN
- Yes
- AC input voltage
- 5 V
- Dimensions (WxDxH)
- 441 x 202 x 45 mm
- Brand
- Techly
- Category
- Video Splitter
- Model
- IDATA HDMI-H44E
- Part number
- IDATA HDMI-H44E
- EAN / UPC
- 8051128101751
- Also known as
- Techly IDATA HDMI-H44E video splitter
Specifications
26 specifications in 9 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Video ports quantity | 8 |
| Video port type | HDMI |
| Video in | 4 |
| HDMI version | 1.3b |
| Ethernet LAN (RJ-45) ports | 8 |
| DC-in jack | Yes |
Features
| Specification | Value |
|---|---|
| Product colour | Black |
| 3D | Yes |
| Colour depth | 12 bit |
| Bandwidth | 255 MHz |
| Remote control included | Yes |
| HDCP | Yes |
| Supported video modes | 480p, 720p, 1080i, 1080p |
| Certification | CE, FCC, UL, WEEE / RAEE |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Cable types supported | Cat5e, Cat6 |
Power
| Specification | Value |
|---|---|
| AC input voltage | 5 V |
| Input current | 4 A |
| Power consumption (typical) | 20 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Dimensions (WxDxH) | 441 x 202 x 45 mm |
| Weight | 2.22 kg |
Packaging data
| Specification | Value |
|---|---|
| Package weight | 6.23 kg |
Packaging content
| Specification | Value |
|---|---|
| Manual | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 70 °C |
| Operating relative humidity (H-H) | 10 - 85% |
Technical details
| Specification | Value |
|---|---|
| Connection to PC | Yes |
