IDATA HDMI-4K8
Model IDATA HDMI-4K8EAN 8057685309852
39 specifications
- Weight390 g
- ColourBlack
- Video ports quantity9
- AC input voltage5 V
- Dimensions (WxDxH)80 x 213 x 19 mm
- Operating temperature (T-T)-10 - 55 °C
Overview
- Weight
- 390 g
- Colour
- Black
- Video ports quantity
- 9
- AC input voltage
- 5 V
- Dimensions (WxDxH)
- 80 x 213 x 19 mm
- Operating temperature (T-T)
- -10 - 55 °C
- Brand
- Techly
- Category
- Video Splitter
- Model
- IDATA HDMI-4K8
- Part number
- IDATA HDMI-4K8
- EAN / UPC
- 8057685309852
- Also known as
- Techly HDMI Splitter 8-way 1.4 4K * 2K 3D Wall Mounts IDATA HDMI-4K8
Specifications
39 specifications in 9 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Video ports quantity | 9 |
| Video port type | HDMI |
| Video in | 1 x HDMI |
| Video out | 8x HDMI |
| HDMI version | 1.4 |
| DC-in jack | Yes |
Features
| Specification | Value |
|---|---|
| Product colour | Black |
| Housing material | Aluminium |
| Maximum resolution | 3840 x 2160 pixels |
| Full HD | Yes |
| 3D | Yes |
| Maximum operating distance | 15 m |
| Maximum refresh rate | 24 Hz |
| Bandwidth | 340 MHz |
| HDCP | Yes |
| Dolby technologies | DTS-HD Master Audio, Dolby Digital Plus, Dolby TrueHD |
| LED indicators | Yes |
| Plug and Play | Yes |
| Power LED | Yes |
| Supported graphics resolutions | 3840 x 2160 |
| Supported video modes | 1080p, 2160p |
| Certification | EC, FCC, RoHS, WEEE, RAEE |
Power
| Specification | Value |
|---|---|
| AC input voltage | 5 V |
| Input current | 3 A |
Weight & dimensions
| Specification | Value |
|---|---|
| Dimensions (WxDxH) | 80 x 213 x 19 mm |
| Weight | 390 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 310 mm |
| Package depth | 112 mm |
| Package height | 28 mm |
| Package weight | 694 g |
| Package type | Box |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Manual | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -10 - 55 °C |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating relative humidity (H-H) | 0 - 95% |
Technical details
| Specification | Value |
|---|---|
| Cascadable | Yes |
| Supported audio channels | 7.1 |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85176990 |
