IDATA HDMI-2SPU
Model IDATA HDMI-2SPUEAN 8057685305434
24 specifications
- ColourBlack
- Video ports quantity3
- AC input voltage5 V
- Dimensions (WxDxH)154 x 69 x 23 mm
- Operating temperature (T-T)0 - 70 °C
Overview
- Colour
- Black
- Video ports quantity
- 3
- AC input voltage
- 5 V
- Dimensions (WxDxH)
- 154 x 69 x 23 mm
- Operating temperature (T-T)
- 0 - 70 °C
- Brand
- Techly
- Category
- Video Splitter
- Model
- IDATA HDMI-2SPU
- Part number
- IDATA HDMI-2SPU
- EAN / UPC
- 8057685305434
- Also known as
- Techly HDMI Splitter 2-Port 340 MHz band. Full 3D. 4K*2K IDATA HDMI-2SPU
Specifications
24 specifications in 6 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Video ports quantity | 3 |
| Video port type | HDMI |
| Video in | 1x HDMI |
| Video out | 2x HDMI |
| DC-in jack | Yes |
Features
| Specification | Value |
|---|---|
| Product colour | Black |
| Maximum resolution | 4096 x 2160 pixels |
| Full HD | Yes |
| 3D | Yes |
| Bandwidth | 340 MHz |
| HDCP | Yes |
| Power LED | Yes |
| Supported graphics resolutions | 3840 x 2160, 4096 x 2160, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 640 x 480 (VGA) |
| Supported video modes | 1080i, 1080p, 2160p, 480i, 480p, 576i, 576p, 720p |
| Certification | FCC |
Power
| Specification | Value |
|---|---|
| AC input voltage | 5 V |
| AC input frequency | 50 - 60 Hz |
| Power consumption (typical) | 2.3 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Dimensions (WxDxH) | 154 x 69 x 23 mm |
Packaging content
| Specification | Value |
|---|---|
| Manual | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 70 °C |
| Storage temperature (T-T) | -10 - 80 °C |
| Operating relative humidity (H-H) | 10 - 85% |
| Storage relative humidity (H-H) | 5 - 95% |
