CV0142 video splitter HDMI 2x HDMI
Model CV0142EAN 4052792057706
32 specifications
- Weight171.3 g
- ColourBlack
- Video ports quantity3
- Output voltage5 V
- Width86 mm
- Operating temperature (T-T)0 - 45 °C
Overview
- Weight
- 171.3 g
- Colour
- Black
- Video ports quantity
- 3
- Output voltage
- 5 V
- Width
- 86 mm
- Operating temperature (T-T)
- 0 - 45 °C
- Brand
- LogiLink
- Category
- Video Splitter
- Model
- CV0142
- Part number
- CV0142
- EAN / UPC
- 4052792057706
- Also known as
- LogiLink CV0142 video splitter HDMI 2x HDMI
Specifications
32 specifications in 8 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Video ports quantity | 3 |
| Video port type | HDMI |
| Video out | 2x HDMI |
| HDMI version | 2.0b |
Features
| Specification | Value |
|---|---|
| Product colour | Black |
| Housing material | Aluminium |
| HD type | 4K Ultra HD |
| 3D | Yes |
| Maximum refresh rate | 60 Hz |
| Bandwidth | 600 MHz |
| HDCP | Yes |
| Dolby technologies | DTS-HD Master Audio, Dolby TrueHD |
| LED indicators | Yes |
| Plug and Play | Yes |
| Certification | CE |
Power
| Specification | Value |
|---|---|
| Output voltage | 5 V |
| Output current | 1 A |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 86 mm |
| Depth | 75 mm |
| Height | 15 mm |
| Weight | 171.3 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 176 mm |
| Package depth | 140 mm |
| Package height | 40 mm |
| Package weight | 310 g |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 45 °C |
| Storage temperature (T-T) | -10 - 80 °C |
| Operating relative humidity (H-H) | 10 - 85% |
| Storage relative humidity (H-H) | 5 - 90% |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85176990 |
| Country of origin | China |
