38157 video splitter HDMI 2x HDMI
Model 38157EAN 4002888381574
28 specifications
- Weight30 g
- ColourBlack
- Video ports quantity3
- Output voltage5 V
- Dimensions (WxDxH)63 x 52 x 12 mm
- Operating temperature (T-T)-15 - 55 °C
Overview
- Weight
- 30 g
- Colour
- Black
- Video ports quantity
- 3
- Output voltage
- 5 V
- Dimensions (WxDxH)
- 63 x 52 x 12 mm
- Operating temperature (T-T)
- -15 - 55 °C
- Brand
- Lindy
- Category
- Video Splitter
- Model
- 38157
- Part number
- 38157
- EAN / UPC
- 4002888381574
- Also known as
- Lindy 38157 video splitter HDMI 2x HDMI
Specifications
28 specifications in 6 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Video ports quantity | 3 |
| Video port type | HDMI |
| Video in | 1x HDMI |
| Video out | 2x HDMI |
Features
| Specification | Value |
|---|---|
| Product colour | Black |
| Housing material | Plastic |
| Maximum resolution | 4096 x 2160 pixels |
| 3D | Yes |
| Maximum operating distance | 20 m |
| Colour depth | 36 bit |
| Maximum refresh rate | 30 Hz |
| Bandwidth | 340 MHz |
| HDCP | Yes |
| Dolby technologies | DTS-HD Master Audio, Dolby TrueHD |
| LED indicators | Activity, Power |
| Supported graphics resolutions | 1920 x 1080 (HD 1080), 4096 x 2160 |
| Supported video modes | 720i, 720p, 1080i, 1080p, 2160p |
| Certification | CE |
Power
| Specification | Value |
|---|---|
| Output voltage | 5 V |
| Output current | 0.35 A |
| Power consumption (typical) | 1.75 W |
| USB powered | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Dimensions (WxDxH) | 63 x 52 x 12 mm |
| Weight | 30 g |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -15 - 55 °C |
| Storage temperature (T-T) | -20 - 80 °C |
Technical details
| Specification | Value |
|---|---|
| Connector type | HDMI, Micro USB B |
| Supported audio channels | 7.1 |
