ATEN 2-Port 8K HDMI Splitter
ATEN

2-Port 8K HDMI Splitter

Model VS5812-ATEAN 4711581521582

28 specifications
  • Weight30 g
  • ColourBlack
  • Video ports quantity3
  • Output voltage5 V
  • Width56.5 mm
  • Operating temperature (T-T)0 - 40 °C
See all specifications

Overview

Weight
30 g
Colour
Black
Video ports quantity
3
Output voltage
5 V
Width
56.5 mm
Operating temperature (T-T)
0 - 40 °C
Brand
ATEN
Model
VS5812-AT
Part number
VS5812-AT
EAN / UPC
4711581521582
Also known as
ATEN 2-Port 8K HDMI Splitter

Specifications

28 specifications in 7 groups

Ports & interfaces

Video ports quantity3
Video port typeHDMI
Video out2x HDMI

Features

Product colourBlack
Housing materialPolycarbonate (PC)
Maximum resolution7680 x 4320 pixels
HD type8K Ultra HD
Maximum operating distance1.5 m
Maximum refresh rate60 Hz
HDCP version2.3
Data transfer rate48 Gbit/s
HDCPYes
LED indicatorsYes

Power

Output voltage5 V
Output current1 A
USB poweredYes

Weight & dimensions

Width56.5 mm
Depth61 mm
Height15.2 mm
Weight30 g

Packaging content

Cables includedUSB Type-A to USB Type-C

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 60 °C
Operating relative humidity (H-H)0 - 80%
Storage relative humidity (H-H)0 - 80%

Logistics data

Harmonized System (HS) code85437090
Products per master (outer) case20 pc(s)
Country of originChina
