4-Port True 4K HDMI Splitter
Model VS4814-ATEAN 4711581521605
28 specifications
- Weight100 g
- ColourBlack
- Video ports quantity5
- Output voltage5 V
- Width56.5 mm
- Operating temperature (T-T)0 - 40 °C
Overview
- Weight
- 100 g
- Colour
- Black
- Video ports quantity
- 5
- Output voltage
- 5 V
- Width
- 56.5 mm
- Operating temperature (T-T)
- 0 - 40 °C
- Brand
- ATEN
- Category
- Video Splitter
- Model
- VS4814-AT
- Part number
- VS4814-AT
- EAN / UPC
- 4711581521605
- Also known as
- ATEN 4-Port True 4K HDMI Splitter
Specifications
28 specifications in 7 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Video ports quantity | 5 |
| Video port type | HDMI |
| Video out | 4x HDMI |
Features
| Specification | Value |
|---|---|
| Product colour | Black |
| Housing material | Polycarbonate (PC) |
| Maximum resolution | 3840 x 2160 pixels |
| HD type | 4K Ultra HD |
| Maximum operating distance | 3 m |
| Maximum refresh rate | 60 Hz |
| HDCP version | 2.2 |
| Data transfer rate | 18 Gbit/s |
| HDCP | Yes |
| LED indicators | Yes |
Power
| Specification | Value |
|---|---|
| Output voltage | 5 V |
| Output current | 1 A |
| USB powered | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 56.5 mm |
| Depth | 145 mm |
| Height | 15.2 mm |
| Weight | 100 g |
Packaging content
| Specification | Value |
|---|---|
| Cables included | USB Type-A to USB Type-C |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
| Storage relative humidity (H-H) | 0 - 80% |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85437090 |
| Products per master (outer) case | 20 pc(s) |
| Country of origin | China |
