8-Port HDMI CAT5e/6 Splitter over Single Cat Cable / 4K / RS232 / HDBaseT
Model VS1818T-AT-GEAN 4719264641350
42 specifications
- Weight3.9 kg
- ColourBlack
- Video ports quantity2
- Cable types supportedCat5, Cat5e, Cat6
- AC input voltage110/220 V
- Width261.1 mm
Overview
- Weight
- 3.9 kg
- Colour
- Black
- Video ports quantity
- 2
- Cable types supported
- Cat5, Cat5e, Cat6
- AC input voltage
- 110/220 V
- Width
- 261.1 mm
- Brand
- ATEN
- Category
- Video Splitter
- Model
- VS1818T-AT-G
- Part number
- VS1818T-AT-G
- EAN / UPC
- 4719264641350
- Also known as
- ATEN 8-Port HDMI CAT5e/6 Splitter over Single Cat Cable / 4K / RS232 / HDBaseT
Specifications
42 specifications in 9 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Video ports quantity | 2 |
| Video port type | HDMI |
| Video out | HDMI |
| Ethernet LAN (RJ-45) ports | 8 |
| Consumer Electronics Control (CEC) support | Yes |
| Serial ports quantity | 1 |
Features
| Specification | Value |
|---|---|
| Product colour | Black |
| Housing material | Metal |
| Maximum resolution | 4096 x 2160 pixels |
| HD type | 4K Ultra HD |
| 3D | Yes |
| Maximum operating distance | 100 m |
| Maximum refresh rate | 60 Hz |
| Bandwidth | 340 MHz |
| Rack mounting | Yes |
| HDCP | Yes |
| Dolby technologies | DTS-HD Master Audio, Dolby TrueHD |
Network
| Specification | Value |
|---|---|
| Cable types supported | Cat5, Cat5e, Cat6 |
Power
| Specification | Value |
|---|---|
| AC input voltage | 110/220 V |
| Power consumption (typical) | 31.7 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 261.1 mm |
| Depth | 437.2 mm |
| Height | 44 mm |
| Weight | 3.9 kg |
Packaging data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
| Package width | 338 mm |
| Package depth | 515 mm |
| Package height | 155 mm |
| Package weight | 5.26 kg |
Packaging content
| Specification | Value |
|---|---|
| Cables included | AC |
| Manual | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
| Storage relative humidity (H-H) | 0 - 80% |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85176990 |
| Master (outer) case net weight | 3.9 kg |
| Master (outer) case width | 338 mm |
| Master (outer) case length | 515 mm |
| Master (outer) case height | 155 mm |
| Master (outer) case gross weight | 5.26 kg |
| Products per master (outer) case | 1 pc(s) |
