43377 video capturing device HDMI/USB 3.2 Gen 1 (3.1 Gen 1)
Model 43377EAN 4002888433778
34 specifications
- Weight94 g
- ColourGrey, Red
- USB portYes
- Power supply typeUSB
- Operating temperature (T-T)-10 - 40 °C
- Warranty period2 year(s)
Overview
- Weight
- 94 g
- Colour
- Grey, Red
- USB port
- Yes
- Power supply type
- USB
- Operating temperature (T-T)
- -10 - 40 °C
- Warranty period
- 2 year(s)
- Brand
- Lindy
- Category
- Video Capturing Device
- Model
- 43377
- Part number
- 43377
- EAN / UPC
- 4002888433778
- Also known as
- Lindy 43377 video capturing device HDMI/USB 3.2 Gen 1 (3.1 Gen 1)
Specifications
34 specifications in 9 groups
Performance
| Specification | Value |
|---|---|
| Product colour | Grey, Red |
| Internal | No |
| Host interface | HDMI/USB 3.2 Gen 1 (3.1 Gen 1) |
| Video capture resolution (max) | 3840 x 2160 pixels |
| Bandwidth | 18 Gbit/s |
| Chipset | EJ511 |
| High Dynamic Range (HDR) supported | Yes |
| Housing material | Acrylonitrile butadiene styrene (ABS) |
| Certification | CE, UKCA, FCC, RoHS & REACH |
Ports & interfaces
| Specification | Value |
|---|---|
| USB port | Yes |
| USB connector type | USB Type-C |
| USB version | 3.2 Gen 1 (3.1 Gen 1) |
| HDMI ports quantity | 2 |
| HDMI in | 1 |
| Number of HDMI outputs | 1 |
| HDMI version | 1.4b |
Power
| Specification | Value |
|---|---|
| Power supply type | USB |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -10 - 40 °C |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating relative humidity (H-H) | 0 - 95% |
Technical details
| Specification | Value |
|---|---|
| Warranty period | 2 year(s) |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 130 mm |
| Depth | 66 mm |
| Height | 17 mm |
| Weight | 94 g |
Other features
| Specification | Value |
|---|---|
| Power requirements | 5VDC 1A |
Packaging content
| Specification | Value |
|---|---|
| Cables included | USB Type-C to USB Type-C |
| Manual | Yes |
| Quantity | 1 |
Packaging data
| Specification | Value |
|---|---|
| Package weight | 201 g |
| Package depth | 46 mm |
| Package height | 174 mm |
| Package width | 103 mm |
| Package type | Box |
