Video Capture Card, Envision
Model CGR-VC-B-01Part no. 3MVC4K6B.0001PEAN 4710483774997
37 specifications
- Weight168 g
- ColourBlack
- Analog signal format systemNot supported
- USB portYes
- Power supply typeUSB
- Windows operating systems supportedWindows 10, Windows 11
Overview
- Weight
- 168 g
- Colour
- Black
- Analog signal format system
- Not supported
- USB port
- Yes
- Power supply type
- USB
- Windows operating systems supported
- Windows 10, Windows 11
- Brand
- COUGAR
- Category
- Video Capturing Device
- Model
- CGR-VC-B-01
- Part number
- 3MVC4K6B.0001P
- EAN / UPC
- 4710483774997
- Also known as
- COUGAR Video Capture Card, Envision
Specifications
37 specifications in 9 groups
Performance
| Specification | Value |
|---|---|
| Product colour | Black |
| Internal | No |
| Host interface | USB 3.2 Gen 1 (3.1 Gen 1) |
| HD type | 4K Ultra HD |
| Video capture resolution (max) | 3840 x 2160 pixels |
| LED indicators | Yes |
| Country of origin | China |
Video
| Specification | Value |
|---|---|
| Analog signal format system | Not supported |
| Supported resolutions | 3840 x 2160p, 2560 x 1440p, 1920 x 1080 |
| Maximum refresh rate | 120 Hz |
| Supported video modes | 1080p, 1440p, 2160p |
Ports & interfaces
| Specification | Value |
|---|---|
| USB port | Yes |
| USB connector type | USB Type-C |
| USB version | 3.2 Gen 1 (3.1 Gen 1) |
| USB ports quantity | 1 |
| HDMI ports quantity | 2 |
| HDMI in | 1 |
| Number of HDMI outputs | 1 |
| HDMI version | 2.0 |
| Headphone outputs | 1 |
| Mic/Line input ports quantity | 1 |
| Mic/Line output ports quantity | 1 |
Power
| Specification | Value |
|---|---|
| Power supply type | USB |
Software
| Specification | Value |
|---|---|
| Windows operating systems supported | Windows 10, Windows 11 |
| Mac compatibility | Yes |
| Mac operating systems supported | Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura, Mac OS X 14.0 Sonoma, Mac OS X 15.0 Sequoia |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | Federal Communications Commission (FCC), RoHS |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 21 mm |
| Depth | 115 mm |
| Height | 93.5 mm |
| Weight | 168 g |
Packaging data
| Specification | Value |
|---|---|
| Package weight | 265 g |
| Package depth | 140 mm |
| Package height | 180 mm |
| Package width | 46 mm |
| Package type | Box |
Packaging content
| Specification | Value |
|---|---|
| Quantity | 1 |
