ATEN CAMLIVE™+(HDMI to USB-C UVC Video Capture with PD3.0 Power Pass-Through)
ATEN

CAMLIVE™+(HDMI to USB-C UVC Video Capture with PD3.0 Power Pass-Through)

Model UC3021-ATEAN 672792011832

40 specifications
  • Weight160 g
  • ColourBlack
  • Maximum frame rate60 fps
  • USB portYes
  • AC input voltage5 V
  • Windows operating systems supportedWindows 10
See all specifications

Overview

Weight
160 g
Colour
Black
Maximum frame rate
60 fps
USB port
Yes
AC input voltage
5 V
Windows operating systems supported
Windows 10
Brand
ATEN
Model
UC3021-AT
Part number
UC3021-AT
EAN / UPC
672792011832, 4710469340055
Also known as
ATEN CAMLIVE™+(HDMI to USB-C UVC Video Capture with PD3.0 Power Pass-Through)

Specifications

40 specifications in 11 groups

Performance

Product colourBlack
InternalNo
Host interfaceUSB 3.2 Gen 1 (3.1 Gen 1)
Housing materialPlastic
Plug and PlayYes

Video

Maximum frame rate60 fps
Supported video modes480p, 720p, 1080p, 2160p

Ports & interfaces

USB portYes
USB connector typeUSB Type-B
USB version3.2 Gen 1 (3.1 Gen 1)
HDMI ports quantity2
HDMI in1
Number of HDMI outputs1
HDMI version2.0
DC-in jackYes

Power

AC input voltage5 V

Software

Windows operating systems supportedWindows 10
Mac compatibilityYes
Other operating systems supportedAndroid

System requirements

Minimum RAM4000 MB
Minimum processorIntel i3 Dual Core 2.8Ghz

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 60 °C
Operating relative humidity (H-H)0 - 80%
Storage relative humidity (H-H)0 - 80%

Weight & dimensions

Width84.9 mm
Depth114.9 mm
Height20 mm
Weight160 g

Other features

Master (outer) case height162 mm
Master (outer) case width326 mm

Packaging data

Package weight280 g
Package depth193 mm
Package height62 mm
Package width140 mm

Logistics data

Harmonized System (HS) code85176990
Master (outer) case gross weight3.42 kg
Master (outer) case length345 mm
Master (outer) case net weight1.6 kg
Products per master (outer) case10 pc(s)
