LevelOne PTZ Network Camera, 2-Megapixel, 802.3af PoE, WDR, 10x Optical Zoom
Model FCS-1041EAN 846359035559
90 specifications
- ConnectivityWired
- TypeIP security camera
- Weight425 g
- ColourSilver
- Form factorCube
- Minimum illumination1 lx
Overview
- Connectivity
- Wired
- Type
- IP security camera
- Weight
- 425 g
- Colour
- Silver
- Form factor
- Cube
- Minimum illumination
- 1 lx
- Brand
- LevelOne
- Category
- Security Camera
- Model
- FCS-1041
- Part number
- FCS-1041
- EAN / UPC
- 846359035559, 4015867189917, 4015867191460
- Also known as
- LevelOne PTZ Network Camera, 2-Megapixel, 802.3af PoE, WDR, 10x Optical Zoom
Specifications
90 specifications in 21 groups
Performance
| Specification | Value |
|---|---|
| Type | IP security camera |
| Connectivity technology | Wired |
| PTZ control | Yes |
| Auto pan mode | Yes |
| Auto patrol mode | Yes |
| Wide Dynamic Range (WDR) | Yes |
| Certification | CE, FCC, ONVIF |
Design
| Specification | Value |
|---|---|
| Form factor | Cube |
| Mounting type | Desk |
| Product colour | Silver |
| LED indicators | Link, Power |
| Country of origin | Taiwan |
Camera
| Specification | Value |
|---|---|
| Minimum illumination | 1 lx |
| Tilt angle range | -45 - 90° |
| Pan range | -177.5 - 177.5° |
| White balance | Auto |
| Camera shutter type | Electronic |
| Camera shutter speed | 1/5 - 1/10000 s |
Image sensor
| Specification | Value |
|---|---|
| Sensor type | CMOS |
| Optical sensor size | 25.4 / 2.7 mm (1 / 2.7") |
| Progressive scan | Yes |
Lens system
| Specification | Value |
|---|---|
| Zoom capability | Yes |
| Optical zoom | 10x |
| Digital zoom | 4x |
| Focal length range | 4.9 - 49 mm |
| Auto focus | Yes |
| Focus adjustment | 1.8 - 3.0 |
Night vision
| Specification | Value |
|---|---|
| Night vision | No |
Video
| Specification | Value |
|---|---|
| Maximum resolution | 1920 x 1080 pixels |
| Total megapixels | 2 MP |
| Video formats supported | MPEG4 |
| Video compression formats | H.264, M-JPEG, MPEG4 |
| Supported video modes | 1080p |
| Frame rate | 30 fps |
| Noise reduction | Yes |
| Automatic gain control | Yes |
| Flip & mirror | Yes |
| Full HD | Yes |
| Image quality adjustment | Brightness, Contrast, Saturation, Sharpness |
| Time stamp overlay | Yes |
Audio
| Specification | Value |
|---|---|
| Audio system | 2-way |
| Built-in microphone | Yes |
| Voice codecs | AMR, G.711 |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Ethernet interface type | Gigabit Ethernet |
| Networking standards | IEEE 802.3, IEEE 802.3af, IEEE 802.3u |
| Supported network protocols | TCP/IP, HTTP, SMTP, FTP, DDNS, UPnP, NTP, PPPoE, DNS, DHCP, RTSP, Samba |
Storage
| Specification | Value |
|---|---|
| Built-in HDD | No |
| Card reader integrated | Yes |
| Compatible memory cards | SD, SDHC |
| Maximum memory card size | 64 GB |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
| Microphone in | Yes |
| Headphone outputs | 1 |
| USB port | Yes |
| Terminal block port | Yes |
| DC-in jack | Yes |
| Interface | RJ-45 |
Security
| Specification | Value |
|---|---|
| Password protection type | User |
| HTTPS encryption | Yes |
| IP address filtering | Yes |
| Motion sensor | Yes |
Management features
| Specification | Value |
|---|---|
| Reset button | Yes |
Power
| Specification | Value |
|---|---|
| Power source type | PoE |
| Power consumption (typical) | 8 W |
| DC output current | 1.5 A |
| Power over Ethernet (PoE) | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 85% |
System requirements
| Specification | Value |
|---|---|
| Windows operating systems supported | Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Win |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 107 mm |
| Depth | 105 mm |
| Height | 110 mm |
| Weight | 425 g |
Sustainability
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
Packaging data
| Specification | Value |
|---|---|
| Package width | 205 mm |
| Package depth | 270 mm |
| Package height | 135 mm |
| Package weight | 1.15 kg |
| Package type | Box |
Packaging content
| Specification | Value |
|---|---|
| Cables included | LAN (RJ-45) |
| Mounting kit | Yes |
| Screws included | Yes |
| Manual | Yes |
| AC adapter included | Yes |
| Quick installation guide | Yes |
| Resource CD | Yes |
Technical details
| Specification | Value |
|---|---|
| Iris | Yes |
| Number of video streams | 2 |
What people say
Reviews & ratings
LevelOne PTZ Network Camera, 2-Megapixel, 802.3af PoE, WDR, 10x Optical Zoom
No reviews yet
Be the first to tell others how LevelOne PTZ Network Camera, 2-Megapixel, 802.3af PoE, WDR, 10x Optical Zoom works for you.
Write the first review- Every rating countsLow ratings are never hidden, removed or pushed down.
- Written by people, never paidNo incentives, no edits — only spam and abuse are removed.
- Private by designOnly the name you choose is shown. No account, no e-mail, nothing tracked.
Compare LevelOne PTZ Network Camera, 2-Megapixel, 802.3af PoE, WDR, 10x Optical Zoom
All security camera comparisons- LevelOne PTZ Network Camera, 2-Megapixel, 802.3af PoE, WDR, 10x Optical Zoom vsLevelOne Fixed Network Camera, 5-Megapixel, PoE 802.3af, Day & NightCompare specs
- LevelOne PTZ Network Camera, 2-Megapixel, 802.3af PoE, WDR, 10x Optical Zoom vsLevelOne HUBBLE Varifocal Dome IP Network Camera, 3-Megapixel, 802.3af PoE, IR LEDs, Vandalproof, two-way audioCompare specs
- LevelOne PTZ Network Camera, 2-Megapixel, 802.3af PoE, WDR, 10x Optical Zoom vsLevelOne Fixed Dome Network Camera,2-Megapixel, Outdoor, PoE 802.3af, Day & Night, IR LEDs, WDR, 3DNRCompare specs
- LevelOne PTZ Network Camera, 2-Megapixel, 802.3af PoE, WDR, 10x Optical Zoom vsLevelOne Fixed Network Camera, 5-Megapixel, 802.3af PoE, Day & Night, WDRCompare specs
- LevelOne PTZ Network Camera, 2-Megapixel, 802.3af PoE, WDR, 10x Optical Zoom vsD-Link Home Monitor 360Compare specs
- LevelOne PTZ Network Camera, 2-Megapixel, 802.3af PoE, WDR, 10x Optical Zoom vsLogiLink WC0030A security camera IP security cameraCompare specs
- LevelOne PTZ Network Camera, 2-Megapixel, 802.3af PoE, WDR, 10x Optical Zoom vsTP-Link NC200 security camera Cube IP security camera IndoorCompare specs
- LevelOne PTZ Network Camera, 2-Megapixel, 802.3af PoE, WDR, 10x Optical Zoom vsSamsung SND-7084R security camera Dome IP security camera Indoor & outdoorCompare specs
