SP-2230N ADF scanner
600 x 600 DPI A4 Black
Model SP-2230NPart no. PA03880-B101EAN 4939761316609
48 specifications
- Weight3.3 kg
- ColourBlack
- Maximum scan size215.9 x 6096 mm
- Scanner typeADF scanner
- Sensor typeDual CIS
- Auto document feeder (ADF) input capacity80 sheets
Overview
- Weight
- 3.3 kg
- Colour
- Black
- Maximum scan size
- 215.9 x 6096 mm
- Scanner type
- ADF scanner
- Sensor type
- Dual CIS
- Auto document feeder (ADF) input capacity
- 80 sheets
- Brand
- Ricoh
- Category
- Scanner
- Model
- SP-2230N
- Part number
- PA03880-B101
- EAN / UPC
- 4939761316609
- Also known as
- Ricoh SP-2230N ADF scanner 600 x 600 DPI A4 Black
Specifications
48 specifications in 15 groups
Scanning
| Specification | Value |
|---|---|
| Maximum scan size | 215.9 x 6096 mm |
| Optical scanning resolution | 600 x 600 DPI |
| Colour scanning | Yes |
| Duplex scanning | Yes |
| Output colour depth | 24 bit |
| Output greyscale depth | 8 bit |
| Output monochrome depth | 1 bit |
| ADF scan speed (b/w, A4) | 30 ppm |
| Duplex ADF scan speed (b/w, A4) | 60 ipm |
Design
| Specification | Value |
|---|---|
| Scanner type | ADF scanner |
| Built-in display | No |
| Product colour | Black |
Performance
| Specification | Value |
|---|---|
| Sensor type | Dual CIS |
| Light source | RGB LED |
| Ultrasonic sensor | Yes |
Input capacity
| Specification | Value |
|---|---|
| Auto document feeder (ADF) input capacity | 80 sheets |
Paper handling
| Specification | Value |
|---|---|
| Maximum ISO A-series paper size | A4 |
| Scanning media types supported | Plain paper, Business Card, Post Card(JPN) |
| Long-paper mode | Yes |
| ISO A-series sizes (A0...A9) | A4, A5, A6 |
| ISO B-series sizes (B0...B9) | B5, B6 |
| Legal | Yes |
| Letter | Yes |
| Card thickness (max) | 1.4 mm |
| Paper tray media weight | 27 - 413 g/m² |
| Maximum scan length | 6.1 m |
Ports & interfaces
| Specification | Value |
|---|---|
| USB port | Yes |
| USB version | 3.2 Gen 1 (3.1 Gen 1) |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 15 W |
| Power supply type | AC |
| Power consumption (standby) | 0.1 W |
| AC input frequency | 50/60 Hz |
| Input voltage | 100 - 240 V |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 292 mm |
| Depth | 163 mm |
| Height | 150 mm |
| Weight | 3.3 kg |
Packaging data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
| Package weight | 4.7 kg |
Packaging content
| Specification | Value |
|---|---|
| Cables included | USB |
| Bundled software | PaperStream IP, PaperStream Capture, PaperStream ClickScan, PaperStream Central Admin, PaperStream Central Admin Agent, Software Operation Panel, Error Recovery Guide |
Sustainability
| Specification | Value |
|---|---|
| Sustainability certificates | ENERGY STAR |
System requirements
| Specification | Value |
|---|---|
| Server operating systems supported | Windows Server 2022, Windows Server 2016, Windows Server 2019 |
| Windows operating systems supported | Windows 11 x64 |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 35 °C |
| Operating relative humidity (H-H) | 15 - 80% |
Other features
| Specification | Value |
|---|---|
| Background colours | White |
