fi-8820 ADF scanner
600 x 600 DPI A3 Black, Grey
Model fi-8820Part no. PA03830-B305-OS5YREAN 4939761314612
51 specifications
- Display10.9 cm (4.3")
- Memory2048 MB
- Weight23 kg
- ColourBlack, Grey
- Maximum scan size305 x 431.8 mm
- Scanner typeADF scanner
Overview
- Display
- 10.9 cm (4.3")
- Memory
- 2048 MB
- Weight
- 23 kg
- Colour
- Black, Grey
- Maximum scan size
- 305 x 431.8 mm
- Scanner type
- ADF scanner
- Brand
- Ricoh
- Category
- Scanner
- Model
- fi-8820
- Part numbers
- PA03830-B305-OS5YR, PA03830-B305, PA03830-B301
- EAN / UPC
- 4939761314612
- Also known as
- Ricoh fi-8820 ADF scanner 600 x 600 DPI A3 Black, Grey
Specifications
51 specifications in 15 groups
Scanning
| Specification | Value |
|---|---|
| Maximum scan size | 305 x 431.8 mm |
| Optical scanning resolution | 600 x 600 DPI |
| Colour scanning | Yes |
| Duplex scanning | Yes |
| ADF scan speed (b/w, A4) | 120 ppm |
Design
| Specification | Value |
|---|---|
| Scanner type | ADF scanner |
| Built-in display | Yes |
| Product colour | Black, Grey |
| Display | LCD |
| Display diagonal | 10.9 cm (4.3") |
| Touchscreen | Yes |
| Control type | Touch |
Performance
| Specification | Value |
|---|---|
| Sensor type | Dual CIS |
| Light source | RGB LED |
| Scan file formats | |
| Daily duty cycle (max) | 100000 pages |
| Scan drivers | ISIS, TWAIN |
| Ultrasonic sensor | Yes |
| Internal memory | 2048 MB |
Input capacity
| Specification | Value |
|---|---|
| Auto document feeder (ADF) input capacity | 500 sheets |
Paper handling
| Specification | Value |
|---|---|
| Maximum ISO A-series paper size | A3 |
| Scanning media types supported | Business Card, Post Card(JPN) |
| ISO A-series sizes (A0...A9) | A3, A4, A5, A6 |
| ISO B-series sizes (B0...B9) | B5, B6 |
| Legal | Yes |
| Letter | Yes |
| Paper tray media weight | 20 - 570 g/m² |
| Maximum scan length | 6.1 m |
Ports & interfaces
| Specification | Value |
|---|---|
| USB port | Yes |
| USB version | 3.2 Gen 1 (3.1 Gen 1) |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 70 W |
| Power supply type | AC |
| AC input frequency | 50/60 Hz |
| Power consumption (PowerSave) | 40 W |
| Sleep mode | Yes |
| Input voltage | 100 - 240 V |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 460 mm |
| Depth | 430 mm |
| Height | 315 mm |
| Weight | 23 kg |
Packaging data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Cables included | AC |
| Bundled software | PaperStream Capture PaperStream IP |
Sustainability
| Specification | Value |
|---|---|
| Sustainability certificates | ENERGY STAR |
System requirements
| Specification | Value |
|---|---|
| Server operating systems supported | Windows Server 2012 R2 x64, Windows Server 2012 x64 |
| Windows operating systems supported | Windows 10, Windows 11 x64 |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 35 °C |
| Operating relative humidity (H-H) | 20 - 80% |
Other features
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
