Ricoh fi-7700 Flatbed & ADF scanner

Ricoh fi-7700 Flatbed & ADF scanner

600 x 600 DPI A3 Black, White

Model fi-7700Part no. PA03740-B001EAN 4058154196878

80 specifications

Weight35 kg
ColourBlack, White
Maximum scan size304.8 x 5588 mm
Scanner typeFlatbed & ADF scanner
Sensor typeTriple CCD
Auto document feeder (ADF) input capacity300 sheets

See all specifications

Overview

Weight: 35 kg
Colour: Black, White
Maximum scan size: 304.8 x 5588 mm
Scanner type: Flatbed & ADF scanner
Sensor type: Triple CCD
Auto document feeder (ADF) input capacity: 300 sheets

Brand: Ricoh
Category: Scanner
Model: fi-7700
Part numbers: PA03740-B001, CG01000-310044
EAN / UPC: 4058154196878, 4939761308987, 097564313943
Also known as: Ricoh fi-7700 Flatbed & ADF scanner 600 x 600 DPI A3 Black, White

Specifications

80 specifications in 15 groups

Scanning

Specification	Value
Maximum scan size	304.8 x 5588 mm
Optical scanning resolution	600 x 600 DPI
Colour scanning	Yes
Duplex scanning	Yes
Output colour depth	24 bit
Output greyscale depth	8 bit
Output monochrome depth	1 bit
ADF scan speed (b/w, A4)	100 ppm
ADF scan speed (colour, A4)	100 ppm
Flatbed scan speed (b/w, A3)	0.6 sec/page
Flatbed scan speed (b/w, A4)	0.6 sec/page
Duplex ADF scan speed (b/w, A4)	200 ipm
Duplex ADF scan speed (colour, A4)	200 ipm
Black/white scanning colour modes	Grayscale, Monochrome

Design

Specification	Value
Scanner type	Flatbed & ADF scanner
Built-in display	Yes
Product colour	Black, White
Display	LCD

Performance

Specification	Value
Sensor type	Triple CCD
Light source	White LED (6x)
Daily duty cycle (max)	30000 pages
Scan drivers	ISIS, TWAIN

Input capacity

Specification	Value
Auto document feeder (ADF) input capacity	300 sheets

Paper handling

Specification	Value
Maximum ISO A-series paper size	A3
Scanning media types supported	Envelopes, Plain paper, Plastic Card, Thin paper
Multi feed detection	Yes
ISO A-series sizes (A0...A9)	A3, A3+, A4, A5, A6, A7, A8
Auto Document Feeder (ADF) media weight	20 - 413 g/m²
Maximum scan area (ADF)	304.8 x 431.8 mm
Minimum scan area (ADF)	50.8 x 69 mm

Ports & interfaces

Specification	Value
USB port	Yes
USB version	3.2 Gen 2 (3.1 Gen 2)
Socket connector type	C5
Standard interfaces	USB 3.2 Gen 1 (3.1 Gen 1)

Power

Specification	Value
Power consumption (typical)	64 W
Power supply type	AC
Power consumption (standby)	0.35 W
Power consumption (off)	0.35 W
Power consumption (PowerSave)	1.7 W
Input voltage	100-240 V

Weight & dimensions

Specification	Value
Width	700 mm
Depth	500 mm
Height	345 mm
Weight	35 kg

Packaging data

Specification	Value
Quantity per pack	1 pc(s)
Package width	697 mm
Package depth	891 mm
Package height	499 mm
Package weight	42 kg

Packaging content

Specification	Value
AC adapter included	Yes
ADF paper chute	Yes
Cables included	AC, USB
Stacker	Yes
Drivers included	Yes
Bundled software	PaperStream IP, PaperStream Capture, Software Operation Panel, Error Recovery Guide, Scanner Central Admin tools

Sustainability

Specification	Value
Sustainability certificates	ENERGY STAR

System requirements

Specification	Value
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2 x64, Windows Server 2008 x64, Windows Server 2012 R2 x64, Windows Server 2012 x64, Windows Server 2016 x64
Windows operating systems supported	Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows

Operational conditions

Specification	Value
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80%

Other features

Specification	Value
Compliance certificates	RoHS
Downloadable software	ScanSnap Manager, Scan to Microsoft SharePoint, ABBYY FineReader, 2D barcode
Selectable background colour	Yes
Background colours	Black, White

Logistics data

Specification	Value
Country of origin	Indonesia
Cardboard packaging weight	1.2 kg
Foil packaging weight	15 g
Glass packaging weight	0 g
Harmonized System (HS) code	8471607000
Metal packaging weight	0 g
Pallet gross length	91 cm
Pallet gross width	142 cm
Pallet height (air)	114.8 cm
Pallet height (sea)	162.7 cm
Paper packaging weight	2.4 kg
Plastic packaging weight	15 g
Polystyrene (EPS/EPP) packaging weight	200 g
Products per pallet (air)	4 pc(s)
Products per pallet (sea)	6 pc(s)
Wood packaging weight	0 g
