Plustek PS286 Plus
Model PS286 PlusPart no. PS286 PLUSEAN 662712426051
56 specifications
- Weight1.66 kg
- ColourBlack, Silver
- Maximum scan size216 x 1270 mm
- Scanner typeADF scanner
- Sensor typeDual CIS
- Auto document feeder (ADF) input capacity50 sheets
Overview
- Weight
- 1.66 kg
- Colour
- Black, Silver
- Maximum scan size
- 216 x 1270 mm
- Scanner type
- ADF scanner
- Sensor type
- Dual CIS
- Auto document feeder (ADF) input capacity
- 50 sheets
- Brand
- Plustek
- Category
- Scanner
- Model
- PS286 Plus
- Part numbers
- PS286 PLUS, PS286PLUS, 0196, ADF PS286 PLUS, 0196UK
- EAN / UPC
- 662712426051, 783064429948, 4042485423581, 4042485424489 +2 more
- Also known as
- Plustek SmartOffice PS286 Plus ADF scanner 600 x 600 DPI A4 Black, Silver
Specifications
56 specifications in 12 groups
Scanning
| Specification | Value |
|---|---|
| Maximum scan size | 216 x 1270 mm |
| Optical scanning resolution | 600 x 600 DPI |
| Colour scanning | Yes |
| Input colour depth | 48 bit |
| Output colour depth | 24 bit |
| Output greyscale depth | 8 bit |
| Output monochrome depth | 1 bit |
| ADF scan speed (b/w, A4) | 25 ppm |
| ADF scan speed (colour, A4) | 8 ppm |
| Black/white scanning colour modes | Grayscale, Monochrome |
Design
| Specification | Value |
|---|---|
| Scanner type | ADF scanner |
| Built-in display | Yes |
| Product colour | Black, Silver |
Performance
| Specification | Value |
|---|---|
| Sensor type | Dual CIS |
| Light source | LED |
| Daily duty cycle (max) | 1500 pages |
| Button functions | Down, Scan, Up |
Input capacity
| Specification | Value |
|---|---|
| Auto document feeder (ADF) input capacity | 50 sheets |
Paper handling
| Specification | Value |
|---|---|
| Maximum ISO A-series paper size | A4 |
| Scanning media types supported | Business Card, Plastic Card |
| ISO A-series sizes (A0...A9) | A4, A5, A6 |
| Letter | Yes |
| Auto Document Feeder (ADF) media weight | 50 - 105 g/m² |
| Maximum scan width | 22 cm |
| Maximum scan length | 2.5 m |
Ports & interfaces
| Specification | Value |
|---|---|
| USB port | Yes |
| USB version | 2.0 |
| Standard interfaces | USB 2.0 |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 18 W |
| Power supply type | DC |
| Power consumption (standby) | 0.5 W |
| Power consumption (off) | 0.3 W |
| Input voltage | 24 V |
| Current | 0.75 A |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 263 mm |
| Depth | 127.5 mm |
| Height | 148 mm |
| Weight | 1.66 kg |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Cables included | USB |
| Calibration sheet included | Yes |
| Cleaning cloth | Yes |
| Quick start guide | Yes |
| Stacker | Yes |
| Drivers included | Yes |
System requirements
| Specification | Value |
|---|---|
| Linux operating systems supported | Yes |
| Mac operating systems supported | Mac OS X 10.10 Yosemite, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks |
| Minimum RAM | 1024 MB |
| Minimum processor | PentiumR IV 2.4 GHz |
| Minimum storage drive space | 2000 MB |
| Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 40 °C |
| Operating relative humidity (H-H) | 20 - 80% |
Other features
| Specification | Value |
|---|---|
| Image formats supported | JPG, PNG, TIF |
| Scan media weight | 50 - 105 g/m² |
| Certification | FCC Class B, CE |
