HD Pro 2 42-in Scanner
Model HD Pro 2 42-in ScannerPart no. 5EK00A#B19EAN 193808855597
56 specifications
- Display39.6 cm (15.6")
- Memory8192 MB
- Weight71 kg
- ColourBlack
- Maximum scan size1067 x 75760 mm
- Scanner typeSheet-fed scanner
Overview
- Display
- 39.6 cm (15.6")
- Memory
- 8192 MB
- Weight
- 71 kg
- Colour
- Black
- Maximum scan size
- 1067 x 75760 mm
- Scanner type
- Sheet-fed scanner
- Brand
- HP
- Category
- Scanner
- Model
- HD Pro 2 42-in Scanner
- Part numbers
- 5EK00A#B19, 5EK00A
- EAN / UPC
- 193808855597, 193015645554, 193808855573, 193808855580 +3 more
- Also known as
- HP HD Pro 2 42-in Scanner
Specifications
56 specifications in 16 groups
Scanning
| Specification | Value |
|---|---|
| Maximum scan size | 1067 x 75760 mm |
| Enhanced scan resolution | 9600 x 9600 DPI |
| Optical scanning resolution | 1200 x 1200 DPI |
| Colour scanning | Yes |
| Duplex scanning | No |
| Input colour depth | 48 bit |
| Film scanning | Yes |
Design
| Specification | Value |
|---|---|
| Scanner type | Sheet-fed scanner |
| Built-in display | Yes |
| Product colour | Black |
| Display diagonal | 39.6 cm (15.6") |
| Touchscreen | Yes |
Performance
| Specification | Value |
|---|---|
| Sensor type | CCD |
| Scan file formats | JPEG, PDF, TIFF |
| Daily duty cycle (max) | 0 pages |
| Scan to | E-mail, Network folder, USB, FTP, Print, File, PC |
| Internal memory | 8192 MB |
Paper handling
| Specification | Value |
|---|---|
| Maximum ISO A-series paper size | A0 |
Ports & interfaces
| Specification | Value |
|---|---|
| USB port | Yes |
| USB version | 3.2 Gen 1 (3.1 Gen 1) |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 130 W |
| Power supply type | AC |
| Power consumption (standby) | 39 W |
| AC input frequency | 50/60 Hz |
| Input voltage | 100-240 V |
| Power consumption (sleep) | 1 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 1530 mm |
| Depth | 930 mm |
| Height | 1660 mm |
| Weight | 71 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 1910 mm |
| Package depth | 680 mm |
| Package height | 800 mm |
| Package weight | 118 kg |
Packaging content
| Specification | Value |
|---|---|
| Cables included | USB, LAN (RJ-45), AC |
| Packaging content | HP HD Pro 2 42-in Scanner, stand, touchscreen (panel PC), quick reference guide, media guides, setup poster, maintenance sheet, copy/scan software, documentation software, Ethernet cable, USB cable, power cords |
Sustainability
| Specification | Value |
|---|---|
| Sustainability certificates | ENERGY STAR |
| Sustainability compliance | Yes |
System requirements
| Specification | Value |
|---|---|
| Compatible operating systems | Windows 11 |
| Windows operating systems supported | Windows 11 |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 35 °C |
| Storage temperature (T-T) | -25 - 55 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 0 - 95% |
Certificates
| Specification | Value |
|---|---|
| Electromagnetic compatibility | Compliance for Class A ITE products: EU (EMC Directive), Russia (EAC) |
Other features
| Specification | Value |
|---|---|
| All-In-One-multitasking | Yes |
| Compatibility | HP DesignJet T920 Printer series; HP DesignJet T930 Printer series; HP DesignJet T940 Printer; HP DesignJet T790 Printer series; HP DesignJet T795 Printer; HP DesignJet T1300 PostScript Printer; HP DesignJet T1500 Printer series; HP DesignJet T1530 Printer series; HP DesignJet T1600 Printer; HP Desi |
| Compliance certificates | RoHS |
| Image formats supported | CALS, DWF, JPEG, TIFF |
| Maximum scan resolution | 9600 x 9600 DPI |
| Media types supported | Non-abrasive paper, vellum, Mylar, sepia, blueprints, plastic, film, plastic laminate, foam board, cardboard, newspaper, tracing paper. Varying condition documents: old, delicate, folded, creased, crumpled, damaged originals (no plywood, stone plates, metal plates or abrasive, dirty, rough, sharp ed |
| Certification | Compliance for Class A ITE products: EU (EMC Directive), Russia (EAC) |
| Box contents | HP HD Pro 2 42-in Scanner, stand, touchscreen (panel PC), quick reference guide, media guides, setup poster, maintenance sheet, copy/scan software, documentation software, Ethernet cable, USB cable, power cords |
| UNSPSC-code | 43211711 |
Logistics data
| Specification | Value |
|---|---|
| Country of origin | China |
