Epson WorkForce DS-860
Model WorkForce DS-860Part no. B11B222401BYEAN 8715946534930
30 specifications
- Weight3.99 kg
- ColourBlack
- Maximum scan size216 x 3048 mm
- Scanner typeADF scanner
- Sensor typeCIS
- Standard input capacity80 sheets
Overview
- Weight
- 3.99 kg
- Colour
- Black
- Maximum scan size
- 216 x 3048 mm
- Scanner type
- ADF scanner
- Sensor type
- CIS
- Standard input capacity
- 80 sheets
- Brand
- Epson
- Category
- Scanner
- Model
- WorkForce DS-860
- Part numbers
- B11B222401BY, B11B222201
- EAN / UPC
- 8715946534930, 010343913264, 103439132646, 715535160005 +1 more
- Also known as
- Epson WorkForce DS-860 ADF scanner 600 x 600 DPI A3 Black
Specifications
30 specifications in 11 groups
Scanning
| Specification | Value |
|---|---|
| Maximum scan size | 216 x 3048 mm |
| Optical scanning resolution | 600 x 600 DPI |
| Colour scanning | Yes |
| Input colour depth | 48 bit |
| Output colour depth | 24 bit |
Design
| Specification | Value |
|---|---|
| Scanner type | ADF scanner |
| Product colour | Black |
Performance
| Specification | Value |
|---|---|
| Sensor type | CIS |
| Daily duty cycle (max) | 6000 pages |
Input capacity
| Specification | Value |
|---|---|
| Standard input capacity | 80 sheets |
Paper handling
| Specification | Value |
|---|---|
| Maximum ISO A-series paper size | A3 |
| ISO A-series sizes (A0...A9) | A4, A5, A6 |
Ports & interfaces
| Specification | Value |
|---|---|
| USB port | Yes |
| USB version | 2.0 |
| Optional connectivity | Ethernet |
| Standard interfaces | USB 2.0 |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 42 W |
| Power supply type | USB |
| Power consumption (standby) | 1.6 W |
| Power consumption (off) | 0.4 W |
| AC input frequency | 50 - 60 Hz |
| Input voltage | 100-240 V |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 300 mm |
| Depth | 221 mm |
| Height | 206 mm |
| Weight | 3.99 kg |
System requirements
| Specification | Value |
|---|---|
| Windows operating systems supported | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 35 °C |
| Operating relative humidity (H-H) | 10 - 80% |
