FastFoto FF-680W
Model FastFoto FF-680WPart no. B11B237401WBEAN 8715946654270
63 specifications
- Weight3.7 kg
- ColourBlack
- Maximum scan size216 x 910 mm
- Scanner typeSheet-fed scanner
- Sensor typeCIS
- Standard input capacity100 sheets
Overview
- Weight
- 3.7 kg
- Colour
- Black
- Maximum scan size
- 216 x 910 mm
- Scanner type
- Sheet-fed scanner
- Sensor type
- CIS
- Standard input capacity
- 100 sheets
- Brand
- Epson
- Category
- Scanner
- Model
- FastFoto FF-680W
- Part numbers
- B11B237401WB, B11B237401DA, B11B237401, B11B237501
- EAN / UPC
- 8715946654270, 9314020628696, 8715946670683
- Also known as
- Epson FastFoto FF-680W Sheet-fed scanner 600 x 600 DPI A4 Black
Specifications
63 specifications in 15 groups
Scanning
| Specification | Value |
|---|---|
| Maximum scan size | 216 x 910 mm |
| Optical scanning resolution | 600 x 600 DPI |
| Colour scanning | Yes |
| Duplex scanning | Yes |
| Input colour depth | 30 bit |
| Input greyscale depth | 10 bit |
| Output colour depth | 24 bit |
| Output greyscale depth | 8 bit |
| Output monochrome depth | 1 bit |
| ADF scan speed (b/w, A4) | 45 ppm |
| ADF scan speed (colour, A4) | 45 ppm |
Design
| Specification | Value |
|---|---|
| Scanner type | Sheet-fed scanner |
| Built-in display | No |
| Product colour | Black |
Performance
| Specification | Value |
|---|---|
| Sensor type | CIS |
| Light source | RGB LED |
| Image quality improvement | Grain reduction, Colour restoration |
| Scan to | E-mail, Network folder |
| Ultrasonic sensor | Yes |
Input capacity
| Specification | Value |
|---|---|
| Standard input capacity | 100 sheets |
Paper handling
| Specification | Value |
|---|---|
| Maximum ISO A-series paper size | A4 |
| Scanning media types supported | Photo paper |
| Media thickness (min) | 0.3 mm |
Ports & interfaces
| Specification | Value |
|---|---|
| USB port | Yes |
| USB version | 3.2 Gen 1 (3.1 Gen 1) |
| Standard interfaces | USB 3.2 Gen 1 (3.1 Gen 1), Wireless LAN |
Network
| Specification | Value |
|---|---|
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 17 W |
| Power consumption (standby) | 9.2 W |
| Power consumption (off) | 0.1 W |
| AC input frequency | 50 - 60 Hz |
| Sleep mode | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 296 mm |
| Depth | 169 mm |
| Height | 176 mm |
| Weight | 3.7 kg |
Packaging data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
| Package width | 256 mm |
| Package depth | 369 mm |
| Package height | 294 mm |
| Package weight | 4.99 kg |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Cables included | USB |
| Cleaning cloth | Yes |
| Quick start guide | Yes |
| Drivers included | Yes |
| Bundled software | Epson ScanSmart |
System requirements
| Specification | Value |
|---|---|
| Compatible operating systems | Mac OS X 10.11.x, Mac OS X 10.12.x, Windows 10, Windows 7, Windows 7, 64-Bit-Version, Windows 8 (32/64 Bit) |
| Mac operating systems supported | Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra |
| Windows operating systems supported | Windows 10, Windows 7, Windows 7 x64, Windows 8, Windows 8 x64 |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 35 °C |
| Operating relative humidity (H-H) | 15 - 80% |
Other features
| Specification | Value |
|---|---|
| Image formats supported | JPEG, TIFF |
| Output resolutions | 300, 600 dpi |
Logistics data
| Specification | Value |
|---|---|
| Products per pallet | 63 pc(s) |
| Country of origin | Indonesia |
| Harmonized System (HS) code | 84716070 |
| Pallet gross weight | 0 g |
| Pallet weight (UK) | 0 g |
| Products per pallet (UK) | 77 pc(s) |
| Products per pallet layer | 9 pc(s) |
| Products per pallet layer (UK) | 11 pc(s) |
