WorkForce ES-C220 ADF + Sheet-fed scanner
600 x 600 DPI Black
Model ES-C220Part no. B11B272202EAN 010343979246
33 specifications
- Weight1.75 kg
- ColourBlack
- Maximum scan size215.9 x 3048 mm
- Scanner typeADF + Sheet-fed scanner
- Sensor typeCIS
- Auto document feeder (ADF) input capacity20 sheets
Overview
- Weight
- 1.75 kg
- Colour
- Black
- Maximum scan size
- 215.9 x 3048 mm
- Scanner type
- ADF + Sheet-fed scanner
- Sensor type
- CIS
- Auto document feeder (ADF) input capacity
- 20 sheets
- Brand
- Epson
- Category
- Scanner
- Model
- ES-C220
- Part number
- B11B272202
- EAN / UPC
- 010343979246
- Also known as
- Epson WorkForce ES-C220 ADF + Sheet-fed scanner 600 x 600 DPI Black
Specifications
33 specifications in 11 groups
Scanning
| Specification | Value |
|---|---|
| Maximum scan size | 215.9 x 3048 mm |
| Optical scanning resolution | 600 x 600 DPI |
| Colour scanning | Yes |
| Duplex scanning | Yes |
| Input colour depth | 30 bit |
| Input greyscale depth | 10 bit |
| Output colour depth | 24 bit |
| Output greyscale depth | 8 bit |
Design
| Specification | Value |
|---|---|
| Scanner type | ADF + Sheet-fed scanner |
| Built-in display | No |
| Product colour | Black |
Performance
| Specification | Value |
|---|---|
| Sensor type | CIS |
| Light source | RGB LED |
| Daily duty cycle (max) | 3500 pages |
Input capacity
| Specification | Value |
|---|---|
| Auto document feeder (ADF) input capacity | 20 sheets |
Ports & interfaces
| Specification | Value |
|---|---|
| USB port | Yes |
| USB version | 2.0/3.2 Gen 1 (3.1 Gen 1) |
| USB connector type | USB Type-C |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 10 W |
| Power supply type | AC |
| Power consumption (off) | 0.1 W |
| Input voltage | 110/120 V |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 297.2 mm |
| Depth | 104.1 mm |
| Height | 124.5 mm |
| Weight | 1.75 kg |
Packaging data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
Packaging content
| Specification | Value |
|---|---|
| Cables included | AC |
System requirements
| Specification | Value |
|---|---|
| Mac operating systems supported | Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura, Mac OS 12.4 |
| Windows operating systems supported | Windows 10, Windows 11, Windows 8, Windows 8.1, Windows 7 |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 35 °C |
| Storage temperature (T-T) | -25 - 60 °C |
| Operating relative humidity (H-H) | 15 - 80% |
