DS-575W II
Model DS-575W IIPart no. B11B263202EAN 010343960220
54 specifications
- Weight3.7 kg
- ColourWhite
- Maximum scan size215.9 x 6096 mm
- Scanner typeSheet-fed scanner
- Light sourceReadyScan LED
- Auto document feeder (ADF) input capacity50 sheets
Overview
- Weight
- 3.7 kg
- Colour
- White
- Maximum scan size
- 215.9 x 6096 mm
- Scanner type
- Sheet-fed scanner
- Light source
- ReadyScan LED
- Auto document feeder (ADF) input capacity
- 50 sheets
- Brand
- Epson
- Category
- Scanner
- Model
- DS-575W II
- Part number
- B11B263202
- EAN / UPC
- 010343960220
- Also known as
- Epson WorkForce DS-570W Power PDF
Specifications
54 specifications in 13 groups
Scanning
| Specification | Value |
|---|---|
| Maximum scan size | 215.9 x 6096 mm |
| Optical scanning resolution | 600 x 600 DPI |
| Colour scanning | Yes |
| Duplex scanning | Yes |
| Input colour depth | 48 bit |
| Input greyscale depth | 10 bit |
| Output colour depth | 24 bit |
| Output greyscale depth | 8 bit |
| ADF scan speed (b/w, A4) | 35 ppm |
| ADF scan speed (colour, A4) | 35 ppm |
Design
| Specification | Value |
|---|---|
| Scanner type | Sheet-fed scanner |
| Built-in display | Yes |
| Product colour | White |
| Display | LCD |
Performance
| Specification | Value |
|---|---|
| Light source | ReadyScan LED |
| Scan file formats | PDF, TIFF |
| Daily duty cycle (max) | 4000 pages |
| Scan to | E-mail, FTP |
| Scan drivers | ISIS, TWAIN, WIA |
Input capacity
| Specification | Value |
|---|---|
| Auto document feeder (ADF) input capacity | 50 sheets |
Paper handling
| Specification | Value |
|---|---|
| Maximum ISO A-series paper size | A4 |
| Scanning media types supported | Business Card, Plastic Card, Post Card(JPN), Thin paper |
| ISO A-series sizes (A0...A9) | A4, A5, A6 |
| ISO B-series sizes (B0...B9) | B5, B6 |
| Legal | Yes |
| Letter | Yes |
| Auto Document Feeder (ADF) media weight | 27 - 413 g/m² |
| Maximum scan area (ADF) | 215.9 x 6.096 mm |
| Minimum scan area (ADF) | 50.8 x 50.8 mm |
Ports & interfaces
| Specification | Value |
|---|---|
| USB port | Yes |
| USB version | 3.2 Gen 1 (3.1 Gen 1) |
| Standard interfaces | USB 3.2 Gen 1 (3.1 Gen 1), Wireless LAN |
Network
| Specification | Value |
|---|---|
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Wi-Fi Direct | Yes |
Power
| Specification | Value |
|---|---|
| Power supply type | AC |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 296 mm |
| Depth | 169 mm |
| Height | 176 mm |
| Weight | 3.7 kg |
Packaging data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
| Package width | 290 mm |
| Package depth | 366 mm |
| Package height | 250 mm |
| Package weight | 4.723 g |
Packaging content
| Specification | Value |
|---|---|
| Cables included | AC, USB |
System requirements
| Specification | Value |
|---|---|
| Linux operating systems supported | Yes |
| Mac operating systems supported | Yes |
| Server operating systems supported | Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012 R2 |
| Windows operating systems supported | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 35 °C |
| Storage temperature (T-T) | -25 - 60 °C |
| Operating relative humidity (H-H) | 15 - 80% |
| Storage relative humidity (H-H) | 15 - 85% |
Energy efficiency
ENERGY STAR certified
Imaging equipment · model B11B263202 · certified Jul 28, 2020 · United States, Canada
| Measurement | Value |
|---|---|
| Sleep-mode power | 1.1 W |
| Standby power | 0.05 W |
