DS-530 II
Model DS-530 IIPart no. B11B261501EAN 9314020633775
38 specifications
- Weight3.72 kg
- ColourWhite
- Maximum scan size215.9 x 6096 mm
- Scanner typeSheet-fed scanner
- Sensor typeCIS
- Auto document feeder (ADF) input capacity50 sheets
Overview
- Weight
- 3.72 kg
- Colour
- White
- Maximum scan size
- 215.9 x 6096 mm
- Scanner type
- Sheet-fed scanner
- Sensor type
- CIS
- Auto document feeder (ADF) input capacity
- 50 sheets
- Brand
- Epson
- Category
- Scanner
- Model
- DS-530 II
- Part numbers
- B11B261501, B11B261203, B11B261401BY, B11B261401
- EAN / UPC
- 9314020633775, 198390002121, 8715946685939, 8715946685908
- Also known as
- Epson WorkForce DS-530 II Sheet-fed scanner 600 x 600 DPI A4 White
Specifications
38 specifications in 11 groups
Scanning
| Specification | Value |
|---|---|
| Maximum scan size | 215.9 x 6096 mm |
| Optical scanning resolution | 600 x 600 DPI |
| Colour scanning | Yes |
| Duplex scanning | Yes |
| Input colour depth | 30 bit |
| Input greyscale depth | 10 bit |
| Output colour depth | 24 bit |
| Output greyscale depth | 8 bit |
| ADF scan speed (b/w, A4) | 35 ppm |
| Duplex ADF scan speed (b/w, A4) | 70 ipm |
Design
| Specification | Value |
|---|---|
| Scanner type | Sheet-fed scanner |
| Built-in display | No |
| Product colour | White |
Performance
| Specification | Value |
|---|---|
| Sensor type | CIS |
| Light source | RGB LED |
| Daily duty cycle (max) | 5500 pages |
| Scan drivers | TWAIN, ISIS |
Input capacity
| Specification | Value |
|---|---|
| Auto document feeder (ADF) input capacity | 50 sheets |
Paper handling
| Specification | Value |
|---|---|
| Maximum ISO A-series paper size | A4 |
| Auto Document Feeder (ADF) media weight | 27 - 413 g/m² |
Ports & interfaces
| Specification | Value |
|---|---|
| USB port | Yes |
| USB version | 3.2 Gen 1 (3.1 Gen 1) |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 11 W |
| Power supply type | AC |
| Power consumption (off) | 0.1 W |
| AC input frequency | 50/60 Hz |
| Sleep mode | Yes |
| Input voltage | 100 - 240 V |
| Power consumption (sleep) | 1 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 297.2 mm |
| Depth | 170.2 mm |
| Height | 175.3 mm |
| Weight | 3.72 kg |
Packaging data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
System requirements
| Specification | Value |
|---|---|
| Mac operating systems supported | Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina |
| Windows operating systems supported | Windows 10, Windows 7, Windows 8, Windows 8.1 |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 35 °C |
| Operating relative humidity (H-H) | 15 - 80% |
Energy efficiency
ENERGY STAR certified
Imaging equipment · model B11B261203 · certified Jul 9, 2024 · United States, Canada
| Measurement | Value |
|---|---|
| Sleep-mode power | 0.79 W |
| Standby power | 0.05 W |
