DS-30000 Solutions Edition
Model DS-30000 Solutions EditionPart no. B11B256401SEEAN 8715946735146
55 specifications
- Display6.81 cm (2.68")
- Weight5.8 kg
- ColourWhite
- Maximum scan size304.8 x 5588 mm
- Scanner typeSheet-fed scanner
- Daily duty cycle (max)30000 pages
Overview
- Display
- 6.81 cm (2.68")
- Weight
- 5.8 kg
- Colour
- White
- Maximum scan size
- 304.8 x 5588 mm
- Scanner type
- Sheet-fed scanner
- Daily duty cycle (max)
- 30000 pages
- Brand
- Epson
- Category
- Scanner
- Model
- DS-30000 Solutions Edition
- Part number
- B11B256401SE
- EAN / UPC
- 8715946735146
- Also known as
- Epson WorkForce DS-30000 Solutions Edition
Specifications
55 specifications in 13 groups
Scanning
| Specification | Value |
|---|---|
| Maximum scan size | 304.8 x 5588 mm |
| Optical scanning resolution | 50 x 1200 DPI |
| Duplex scanning | Yes |
| Input colour depth | 30 bit |
| Output colour depth | 24 bit |
| ADF scan speed (b/w, A4) | 70 ppm |
| ADF scan speed (colour, A4) | 70 ppm |
| Duplex ADF scan speed (b/w, A4) | 140 ipm |
| Duplex ADF scan speed (colour, A4) | 140 ipm |
Design
| Specification | Value |
|---|---|
| Scanner type | Sheet-fed scanner |
| Built-in display | Yes |
| Product colour | White |
| Display | LCD |
| Display diagonal | 6.81 cm (2.68") |
| Touchscreen | Yes |
| Colour display | Yes |
| Control type | Touch |
Performance
| Specification | Value |
|---|---|
| Daily duty cycle (max) | 30000 pages |
| Image quality improvement | Dust removal, Noise reduction, Unsharp mask |
| Scan to | E-mail, FTP, Network folder, Print, USB, PC |
| Scan drivers | TWAIN, SANE, WIA, ICA, ISIS |
| Ultrasonic sensor | Yes |
| Scanning noise level | 64 dB |
Input capacity
| Specification | Value |
|---|---|
| Standard input capacity | 120 sheets |
| Auto document feeder (ADF) input capacity | 120 sheets |
Paper handling
| Specification | Value |
|---|---|
| ISO A-series sizes (A0...A9) | A3, A4, A5, A6, A7 |
| ISO B-series sizes (B0...B9) | B6, B5, B4 |
| Media thickness (min) | 6 mm |
| Paper tray media weight | 27 - 413 g/m² |
| Auto Document Feeder (ADF) media weight | 27 - 413 g/m² |
| Maximum scan area (ADF) | 50.8 x 69 mm |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 371 mm |
| Depth | 208 mm |
| Height | 219 mm |
| Weight | 5.8 kg |
Packaging data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
| Package width | 330 mm |
| Package depth | 460 mm |
| Package height | 325 mm |
| Package weight | 7.5 kg |
Packaging content
| Specification | Value |
|---|---|
| Bundled software | Epson Document Capture (Mac only), Epson Document Capture Pro (Windows only), Epson Scan 2 |
System requirements
| Specification | Value |
|---|---|
| Compatible operating systems | Mac OS 10.6+, Windows 10, Windows 10 (32/64 bit), Windows 11, Windows 7, Windows 8, Windows 8.1, Windows Server 2003, Windows Server 2008 (32/64bit), Windows Server 2012 R2, Windows Server 2016, Windows Vista, Windows XP SP3 |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 35 °C |
| Storage temperature (T-T) | 60 - 25 °C |
| Operating relative humidity (H-H) | 15 - 80% |
| Storage relative humidity (H-H) | 15 - 85% |
Other features
| Specification | Value |
|---|---|
| Image formats supported | BMP, JPEG, TIFF, MTIFF, PNG |
| Interface | USB - compatible with USB 2.0 specification, USB 3.2 Gen 1x1 |
| Box contents | AC adapter, Main unit, USB 3.0 cable, User guide, User manual (CD) |
| Linear scan speed (metric) | Monochrome:70 pages/min - Color:70 pages/min measured with Size: A4 , Resolution: 300 dpi, Monochrome:140 image/min - Color:140 image/min measured with Size: A4 , Resolution: 300 dpi |
| Output resolutions | 600 DPI |
| Printer features | Advanced Colour Dropout / Enhance, Skip blank page, Punch holes removal, Automatic de-skew, RGB colour enhance, Auto-rotation, Text enhancement, Descreening, Barcode Recognition |
| Scanner features | Advanced Colour Dropout / Enhance, Skip blank page, Punch holes removal, Automatic de-skew, RGB colour enhance, Auto-rotation, Text enhancement, Descreening, Barcode Recognition |
Technical details
| Specification | Value |
|---|---|
| Data compression | TIFF Compression (JPEG(7) , CITT G4, LZW), PDF Compression, JPEG compression |
Logistics data
| Specification | Value |
|---|---|
| Country of origin | Indonesia |
