WorkForce B11B255201 scanner Sheet-fed scanner
600 x 600 DPI A3 White
Model B11B255201EAN 010343952195
56 specifications
- Display6.86 cm (2.7")
- Weight5.8 kg
- ColourWhite
- Maximum scan size304.8 x 5588 mm
- Scanner typeSheet-fed scanner
- Sensor typeDual CIS
Overview
- Display
- 6.86 cm (2.7")
- Weight
- 5.8 kg
- Colour
- White
- Maximum scan size
- 304.8 x 5588 mm
- Scanner type
- Sheet-fed scanner
- Sensor type
- Dual CIS
- Brand
- Epson
- Category
- Scanner
- Model
- B11B255201
- Part number
- B11B255201
- EAN / UPC
- 010343952195
- Also known as
- Epson WorkForce B11B255201 scanner Sheet-fed scanner 600 x 600 DPI A3 White
Specifications
56 specifications in 12 groups
Scanning
| Specification | Value |
|---|---|
| Maximum scan size | 304.8 x 5588 mm |
| Optical scanning resolution | 600 x 600 DPI |
| Colour scanning | Yes |
| Duplex scanning | Yes |
| Input colour depth | 30 bit |
| Input greyscale depth | 10 bit |
| Output colour depth | 24 bit |
| Output greyscale depth | 8 bit |
| Output monochrome depth | 24 bit |
Design
| Specification | Value |
|---|---|
| Scanner type | Sheet-fed scanner |
| Built-in display | Yes |
| Product colour | White |
| Display | LCD |
| Display diagonal | 6.86 cm (2.7") |
| Touchscreen | Yes |
| Colour display | Yes |
Performance
| Specification | Value |
|---|---|
| Sensor type | Dual CIS |
| Light source | White LED |
| Scan file formats | BMP, JPEG, PDF, PNG, PPTX, TIFF, XLSX |
| Daily duty cycle (max) | 40000 pages |
| Scan to | E-mail, FTP, HTTP, PC, USB |
| Scan drivers | ICA, ISIS, TWAIN, WIA |
| Ultrasonic double sheet detection | Yes |
| Scanning noise level | 67 dB |
| Sound pressure level (max) | 53 dB |
Input capacity
| Specification | Value |
|---|---|
| Auto document feeder (ADF) input capacity | 120 sheets |
Paper handling
| Specification | Value |
|---|---|
| Maximum ISO A-series paper size | A3 |
| Scanning media types supported | Business Card, Plastic Card, Post Card(JPN) |
| ISO A-series sizes (A0...A9) | A3, A4, A5, A6, A7, A8 |
| Legal | Yes |
| Auto Document Feeder (ADF) media weight | 20 - 413 g/m² |
| Maximum scan area (ADF) | 304.8 x 5588 mm |
| Minimum scan area (ADF) | 50.8 x 69 mm |
Ports & interfaces
| Specification | Value |
|---|---|
| USB port | Yes |
| USB version | 3.2 Gen 1 (3.1 Gen 1) |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 20 W |
| Power supply type | AC |
| Power consumption (standby) | 11 W |
| Power consumption (off) | 0.1 W |
| Sleep mode | Yes |
| Input voltage | 100 - 240 V |
| Power consumption (sleep) | 1.4 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 371 mm |
| Depth | 208 mm |
| Height | 219 mm |
| Weight | 5.8 kg |
Packaging data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
Packaging content
| Specification | Value |
|---|---|
| Cables included | USB |
| Bundled software | Epson Document Capture (Mac), Epson Document Capture Pro (Windows), Epson Scan 2 |
System requirements
| Specification | Value |
|---|---|
| Mac operating systems supported | Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks |
| Server operating systems supported | Windows Server 2003, Windows Server 2008, Windows Server 2008 x64, Windows Server 2012 R2, Windows Server 2016 |
| Windows operating systems supported | Windows 10, Windows 7, Windows 8, Windows 8.1, Windows Vista, Windows XP |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 35 °C |
| Storage temperature (T-T) | 25 - 60 °C |
| Operating relative humidity (H-H) | 15 - 80% |
| Storage relative humidity (H-H) | 15 - 85% |
Energy efficiency
ENERGY STAR certified
Imaging equipment · model B11B255201 · certified Oct 25, 2019 · United States, Canada
| Measurement | Value |
|---|---|
| Sleep-mode power | 0.93 W |
| Standby power | 0.04 W |
