WorkForce B11B253201 scanner Sheet-fed scanner
600 x 600 DPI A4 Black
Model B11B253201EAN 010343945074
58 specifications
- Weight300 g
- ColourBlack
- Maximum scan size216 x 1828.8 mm
- Scanner typeSheet-fed scanner
- Sensor typeCIS
- Maximum ISO A-series paper sizeA4
Overview
- Weight
- 300 g
- Colour
- Black
- Maximum scan size
- 216 x 1828.8 mm
- Scanner type
- Sheet-fed scanner
- Sensor type
- CIS
- Maximum ISO A-series paper size
- A4
- Brand
- Epson
- Category
- Scanner
- Model
- B11B253201
- Part number
- B11B253201
- EAN / UPC
- 010343945074
- Also known as
- Epson WorkForce B11B253201 scanner Sheet-fed scanner 600 x 600 DPI A4 Black
Specifications
58 specifications in 13 groups
Scanning
| Specification | Value |
|---|---|
| Maximum scan size | 216 x 1828.8 mm |
| Enhanced scan resolution | 1200 x 1200 DPI |
| Optical scanning resolution | 600 x 600 DPI |
| Colour scanning | Yes |
| Duplex scanning | No |
| Input colour depth | 16 bit |
| Input greyscale depth | 16 bit |
| Output colour depth | 24 bit |
| Output greyscale depth | 8 bit |
| ADF scan speed (b/w, A4) | 15 ppm |
| ADF scan speed (greyscale, A4) | 15 ppm |
| ADF scan speed (colour, A4) | 15 ppm |
| Scan speed (b/w, high res, A4) | 4 sec/page |
| Scan speed (b/w, low res, A4) | 4 sec/page |
| Scan speed (colour, high res, A4) | 4 sec/page |
| Scan speed (colour, low res, A4) | 4 sec/page |
| Movement resolution | 300 DPI |
Design
| Specification | Value |
|---|---|
| Scanner type | Sheet-fed scanner |
| Built-in display | Yes |
| Product colour | Black |
Performance
| Specification | Value |
|---|---|
| Sensor type | CIS |
| Light source | RGB LED |
| Scan file formats | JPEG, PDF |
| Daily duty cycle (max) | 300 pages |
| Scan drivers | ICA, SANE, WIA |
Paper handling
| Specification | Value |
|---|---|
| Maximum ISO A-series paper size | A4 |
| Scanning media types supported | Business Card, Plastic Card |
| ISO A-series sizes (A0...A9) | A4, A5, A6, A8 |
| ISO B-series sizes (B0...B9) | B5 |
| Legal | Yes |
| Letter | Yes |
| Card thickness (max) | 1.2 mm |
Ports & interfaces
| Specification | Value |
|---|---|
| USB port | Yes |
| USB version | 2.0 |
| USB connector type | USB Type-B |
Network
| Specification | Value |
|---|---|
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 3.1 W |
| Power supply type | USB/Battery |
| Power consumption (standby) | 2.4 W |
| Power consumption (off) | 0.2 W |
| Sleep mode | Yes |
| Power consumption (sleep) | 1.9 W |
| Battery type | Built-in battery |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 272 mm |
| Depth | 47 mm |
| Height | 34 mm |
| Weight | 300 g |
Packaging content
| Specification | Value |
|---|---|
| Cables included | USB |
System requirements
| Specification | Value |
|---|---|
| Mac operating systems supported | Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina |
| Server operating systems supported | Windows Server 2003, Windows Server 2008, Windows Server 2008 x64, Windows Server 2012 R2, Windows Server 2016 |
| Windows operating systems supported | Windows 10, Windows 7, Windows 8, Windows 8.1 |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 35 °C |
| Storage temperature (T-T) | -25 - 60 °C |
| Operating relative humidity (H-H) | 10 - 85% |
| Storage relative humidity (H-H) | 10 - 90% |
Other features
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
Logistics data
| Specification | Value |
|---|---|
| Country of origin | China |
