Epson WorkForce B11B248301 scanner Sheet-fed scanner
600 x 600 DPI A4 White
Model B11B248301
55 specifications
- Weight3.63 kg
- ColourWhite
- Maximum scan size215.9 x 215.9 mm
- Scanner typeSheet-fed scanner
- Sensor typeCIS
- Auto document feeder (ADF) input capacity100 sheets
Overview
- Weight
- 3.63 kg
- Colour
- White
- Maximum scan size
- 215.9 x 215.9 mm
- Scanner type
- Sheet-fed scanner
- Sensor type
- CIS
- Auto document feeder (ADF) input capacity
- 100 sheets
- Brand
- Epson
- Category
- Scanner
- Model
- B11B248301
- Part number
- B11B248301
- Also known as
- Epson WorkForce B11B248301 scanner Sheet-fed scanner 600 x 600 DPI A4 White
Specifications
55 specifications in 12 groups
Scanning
| Specification | Value |
|---|---|
| Maximum scan size | 215.9 x 215.9 mm |
| Optical scanning resolution | 600 x 600 DPI |
| Colour scanning | Yes |
| Duplex scanning | Yes |
| Input colour depth | 30 bit |
| Output colour depth | 24 bit |
| Output greyscale depth | 8 bit |
| Output monochrome depth | 8 bit |
| Film scanning | No |
| ADF scan speed (b/w, A4) | 45 ppm |
| ADF scan speed (colour, A4) | 45 ppm |
| Duplex ADF scan speed (b/w, A4) | 90 ipm |
| Duplex ADF scan speed (colour, A4) | 90 ipm |
Design
| Specification | Value |
|---|---|
| Scanner type | Sheet-fed scanner |
| Built-in display | Yes |
| Product colour | White |
| Display | LCD |
Performance
| Specification | Value |
|---|---|
| Sensor type | CIS |
| Light source | LED |
| Scan file formats | JPG, PDF, TIFF |
| Daily duty cycle (max) | 5000 pages |
| Scan to | E-mail, FTP, HTTP |
| Scan drivers | ISIS, TWAIN, WIA |
Input capacity
| Specification | Value |
|---|---|
| Auto document feeder (ADF) input capacity | 100 sheets |
Paper handling
| Specification | Value |
|---|---|
| Maximum ISO A-series paper size | A4 |
| ISO A-series sizes (A0...A9) | A4, A5, A6 |
| ISO B-series sizes (B0...B9) | B5, B6 |
| Auto Document Feeder (ADF) media weight | 27 - 413 g/m² |
| Maximum scan area (ADF) | 215.9 x 6096 mm |
| Minimum scan area (ADF) | 50.8 x 50.8 mm |
Ports & interfaces
| Specification | Value |
|---|---|
| USB port | Yes |
| USB version | 3.2 Gen 1 (3.1 Gen 1) |
| Optional connectivity | Ethernet |
| Standard interfaces | USB 3.2 Gen 1 (3.1 Gen 1) |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Supported network protocols | IPv6 , TCP/IP, DHCP, DNS, SNMP, SLP |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 17 W |
| Power supply type | AC |
| Power consumption (standby) | 1.2 W |
| Power consumption (off) | 0.1 W |
| Input voltage | 100-240 V |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 296 mm |
| Depth | 169 mm |
| Height | 176 mm |
| Weight | 3.63 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 355.6 mm |
| Package depth | 228.6 mm |
| Package height | 279.4 mm |
| Package weight | 4.54 kg |
System requirements
| Specification | Value |
|---|---|
| Mac operating systems supported | Yes |
| Windows operating systems supported | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 35 °C |
| Storage temperature (T-T) | -25 - 60 °C |
| Operating relative humidity (H-H) | 15 - 80% |
| Storage relative humidity (H-H) | 15 - 85% |
Energy efficiency
ENERGY STAR certified
Imaging equipment · model B11B248301 · certified Apr 19, 2017 · United States, Canada
| Measurement | Value |
|---|---|
| Sleep-mode power | 1 W |
| Standby power | 0.03 W |
