Epson B11B228202 scanner ADF scanner

Epson B11B228202 scanner ADF scanner

600 x 600 DPI Black, White

Model B11B228202

54 specifications

Weight3.67 kg
ColourBlack, White
Maximum scan size215.9 x 6096 mm
Scanner typeADF scanner
Sensor typeCIS
Auto document feeder (ADF) input capacity50 sheets

See all specifications

Overview

Weight: 3.67 kg
Colour: Black, White
Maximum scan size: 215.9 x 6096 mm
Scanner type: ADF scanner
Sensor type: CIS
Auto document feeder (ADF) input capacity: 50 sheets

Brand: Epson
Category: Scanner
Model: B11B228202
Part number: B11B228202
Also known as: Epson B11B228202 scanner ADF scanner 600 x 600 DPI Black, White

Specifications

54 specifications in 15 groups

Scanning

Specification	Value
Maximum scan size	215.9 x 6096 mm
Enhanced scan resolution	1200 x 1200 DPI
Optical scanning resolution	600 x 600 DPI
Colour scanning	Yes
Duplex scanning	Yes
Input colour depth	30 bit
Output colour depth	24 bit
Output monochrome depth	1 bit
ADF scan speed (b/w, A4)	35 ppm
Duplex ADF scan speed (b/w, A4)	70 ipm

Design

Specification	Value
Scanner type	ADF scanner
Built-in display	No
Product colour	Black, White

Performance

Specification	Value
Sensor type	CIS
Light source	RGB LED
Daily duty cycle (max)	4000 pages
Scan drivers	ISIS, TWAIN

Input capacity

Specification	Value
Auto document feeder (ADF) input capacity	50 sheets

Paper handling

Specification	Value
Media thickness (min)	1.24 mm
Auto Document Feeder (ADF) media weight	27 - 413 g/m²
Maximum scan area (ADF)	215.9 x 6096 mm
Minimum scan area (ADF)	50.8 x 50.8 mm

Ports & interfaces

Specification	Value
USB port	Yes
USB version	3.2 Gen 1 (3.1 Gen 1)
Optional connectivity	Ethernet
Standard interfaces	USB 3.2 Gen 1 (3.1 Gen 1), Wireless LAN

Network

Specification	Value
Wi-Fi	Yes
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ethernet LAN	Yes

Power

Specification	Value
Power consumption (typical)	17 W
Power supply type	AC
Power consumption (standby)	9.2 W
Power consumption (off)	0.1 W
Power consumption (PowerSave)	1.4 W
Input voltage	100-240 V
Current	1.2 A

Weight & dimensions

Specification	Value
Width	167 mm
Depth	294 mm
Height	175 mm
Weight	3.67 kg

Packaging data

Specification	Value
Package width	365 mm
Package depth	251 mm
Package height	292 mm
Package weight	4.81 kg

Packaging content

Specification	Value
AC adapter included	Yes
Cables included	USB
Bundled software	Epson Scan 2, ABBYY FineReader Sprint, NewSoft Presto! BizCard OCR, EMC ISIS

Sustainability

Specification	Value
Sustainability certificates	ENERGY STAR

System requirements

Specification	Value
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.9 Mavericks
Windows operating systems supported	Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64,

Operational conditions

Specification	Value
Operating temperature (T-T)	5 - 35 °C
Storage temperature (T-T)	-25 - 60 °C
Operating relative humidity (H-H)	10 - 80%

Other features

Specification	Value
Compliance certificates	RoHS

Energy efficiency

ENERGY STAR certified

Imaging equipment · model B11B228202 · certified May 17, 2017 · United States, Canada

Measurement	Value
Sleep-mode power	1.4 W
Standby power	0.03 W
