Canon imageFORMULA CR-L1
300 x 300 DPI Black, Grey
Model CR-L1Part no. 3595C003EAN 4528472110318
32 specifications
- Weight2.1 kg
- ColourBlack, Grey
- Maximum scan size108 x 228 mm
- Built-in displayNo
- Sensor typeCMOS CIS
- Auto document feeder (ADF) input capacity50 sheets
Overview
- Weight
- 2.1 kg
- Colour
- Black, Grey
- Maximum scan size
- 108 x 228 mm
- Built-in display
- No
- Sensor type
- CMOS CIS
- Auto document feeder (ADF) input capacity
- 50 sheets
- Brand
- Canon
- Category
- Scanner
- Model
- CR-L1
- Part numbers
- 3595C003, 3595C002
- EAN / UPC
- 4528472110318, 013803315158, 4528472108643, 5284721086436
- Also known as
- Canon imageFORMULA CR-L1 300 x 300 DPI Black, Grey
Specifications
32 specifications in 11 groups
Scanning
| Specification | Value |
|---|---|
| Maximum scan size | 108 x 228 mm |
| Optical scanning resolution | 300 x 300 DPI |
| Colour scanning | Yes |
| Duplex scanning | Yes |
| Output colour depth | 24 bit |
| Greyscale levels | 256 |
Design
| Specification | Value |
|---|---|
| Built-in display | No |
| Product colour | Black, Grey |
Performance
| Specification | Value |
|---|---|
| Sensor type | CMOS CIS |
| Light source | RGB LED |
| Daily duty cycle (max) | 3000 pages |
Input capacity
| Specification | Value |
|---|---|
| Auto document feeder (ADF) input capacity | 50 sheets |
Paper handling
| Specification | Value |
|---|---|
| Long-paper mode | Yes |
| Media thickness (min) | 0.08 mm |
| Card thickness (max) | 0.2 mm |
| Auto Document Feeder (ADF) media weight | 64 - 157 g/m² |
Ports & interfaces
| Specification | Value |
|---|---|
| USB port | Yes |
| USB version | 2.0 |
| Standard interfaces | USB 2.0 |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 15.8 W |
| AC input frequency | 50 - 60 Hz |
| Input voltage | 220-240 V |
| Power consumption (sleep) | 2.3 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 140 mm |
| Depth | 223 mm |
| Height | 188 mm |
| Weight | 2.1 kg |
Packaging content
| Specification | Value |
|---|---|
| Bundled software | Ranger driver + IQA, Canon Scanning Utility |
System requirements
| Specification | Value |
|---|---|
| Server operating systems supported | Windows Server 2008 R2, Windows Server 2012 R2, Windows Server 2016 |
| Windows operating systems supported | Windows 10, Windows 7, Windows 8.1 |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 10 - 32.5 °C |
| Operating relative humidity (H-H) | 20 - 80% |
Energy efficiency
ENERGY STAR certified
Imaging equipment · model 6130110 · certified Sep 25, 2019 · United States, Canada
| Measurement | Value |
|---|---|
| Sleep-mode power | 2.24 W |
| Standby power | 0.16 W |
