Canon imageFORMULA CR-150N ADF scanner Specs

Overview

Weight: 3.5 kg
Colour: Graphite
Maximum scan size: 108 x 245 mm
Scanner type: ADF scanner
Sensor type: CMOS CIS
Auto document feeder (ADF) input capacity: 150 sheets

Brand: Canon
Category: Scanner
Model: CR-150N
Part number: 2286C002
EAN / UPC: 4528472107981, 4528472110332
Also known as: Canon imageFORMULA CR-150N ADF scanner 200 x 200 DPI Graphite

Specifications

47 specifications in 15 groups

Scanning

Specification	Value
Maximum scan size	108 x 245 mm
Enhanced scan resolution	300 x 300 DPI
Optical scanning resolution	200 x 200 DPI
Colour scanning	Yes
Duplex scanning	Yes
Input colour depth	24 bit
Greyscale levels	256
ADF scan speed (b/w, A4)	150 ppm
ID card resolutions	600 x 600 DPI
Black/white scanning colour modes	Grayscale

Design

Specification	Value
Scanner type	ADF scanner
Built-in display	No
Product colour	Graphite

Performance

Specification	Value
Sensor type	CMOS CIS
Light source	RGB LED
Daily duty cycle (max)	12000 pages
Built-in OCR	Yes
Scan to	PC
Scan drivers	ISIS, TWAIN
Ultrasonic sensor	Yes

Input capacity

Specification	Value
Auto document feeder (ADF) input capacity	150 sheets

Paper handling

Specification	Value
Long-paper mode	Yes
Media thickness (min)	0.08 mm
Auto Document Feeder (ADF) media weight	64 - 157 g/m²
Maximum scan width	24.5 cm
Maximum scan length	24.5 cm

Ports & interfaces

Specification	Value
USB port	Yes
USB version	2.0
USB connector type	USB Type-A, USB Type-B

Network

Specification	Value
Ethernet LAN	Yes

Power

Specification	Value
Power consumption (typical)	23 W
Power supply type	AC
Sleep mode	Yes
Input voltage	220 - 240 V
Power consumption (sleep)	2.2 W

Weight & dimensions

Specification	Value
Width	170 mm
Depth	239 mm
Height	204 mm
Weight	3.5 kg

Packaging data

Specification	Value
Quantity per pack	1 pc(s)

Packaging content

Specification	Value
Cables included	AC

System requirements

Specification	Value
Server operating systems supported	Windows Server 2008 R2
Windows operating systems supported	Windows 10, Windows 7, Windows 8.1, Windows Vista

Operational conditions

Specification	Value
Operating temperature (T-T)	10 - 32.5 °C
Operating relative humidity (H-H)	20 - 80%

Other features

Specification	Value
Certification	RoHS, Energy Star

Logistics data

Specification	Value
Harmonized System (HS) code	84716070
