imageFORMULA DR-C360
Model 7629C003EAN 4528472112893
44 specifications
- Weight3.2 kg
- ColourBlack
- Maximum scan size216 x 356 mm
- Scanner typeADF scanner
- Sensor typeCMOS CIS
- Standard input capacity100 sheets
Overview
- Weight
- 3.2 kg
- Colour
- Black
- Maximum scan size
- 216 x 356 mm
- Scanner type
- ADF scanner
- Sensor type
- CMOS CIS
- Standard input capacity
- 100 sheets
- Brand
- Canon
- Category
- Scanner
- Model
- 7629C003
- Part number
- 7629C003
- EAN / UPC
- 4528472112893
- Also known as
- Canon imageFORMULA DR-C360
Specifications
44 specifications in 11 groups
Scanning
| Specification | Value |
|---|---|
| Maximum scan size | 216 x 356 mm |
| Optical scanning resolution | 600 x 600 DPI |
| Colour scanning | Yes |
| Duplex scanning | Yes |
| ADF scan speed (b/w, A4) | 60 ppm |
| ADF scan speed (colour, A4) | 60 ppm |
| Duplex ADF scan speed (b/w, A4) | 120 ipm |
| Duplex ADF scan speed (colour, A4) | 120 ipm |
| Black/white scanning colour modes | Grayscale, Monochrome |
Design
| Specification | Value |
|---|---|
| Scanner type | ADF scanner |
| Built-in display | Yes |
| Product colour | Black |
| Display | LCD |
| Touchscreen | No |
Performance
| Specification | Value |
|---|---|
| Sensor type | CMOS CIS |
| Light source | RGB LED |
| Daily duty cycle (max) | 13000 pages |
| Built-in OCR | Yes |
| Barcode reader | Yes |
| Ultrasonic double sheet detection | Yes |
Input capacity
| Specification | Value |
|---|---|
| Standard input capacity | 100 sheets |
Paper handling
| Specification | Value |
|---|---|
| Maximum ISO A-series paper size | A4 |
| Media thickness (min) | 0.04 mm |
| Card thickness (max) | 0.3 mm |
| Plastic card media weight | 128 - 255 g/m² |
| Maximum scan width | 21.6 cm |
| Maximum scan length | 35.6 cm |
Ports & interfaces
| Specification | Value |
|---|---|
| USB port | Yes |
| USB version | 3.2 Gen 2 (3.1 Gen 2) |
| USB connector type | USB Type-C |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 15.6 W |
| Power supply type | AC |
| Power consumption (standby) | 0.6 W |
| Power consumption (off) | 0.1 W |
| AC input frequency | 50/60 Hz |
| Input voltage | 220 - 240 V |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 283 mm |
| Depth | 223 mm |
| Height | 218 mm |
| Weight | 3.2 kg |
System requirements
| Specification | Value |
|---|---|
| Windows operating systems supported | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 10 - 32.5 °C |
| Operating relative humidity (H-H) | 20 - 80% |
Other features
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
