Brother PDS-5000F scanner Flatbed & ADF scanner

600 x 600 DPI A4 Black

Model PDS-5000FEAN 012502642701

61 specifications

Memory512 MB
Weight6.7 kg
ColourBlack
Maximum scan size216 x 5994 mm
Scanner typeFlatbed & ADF scanner
Sensor typeCCD

See all specifications

Overview

Memory: 512 MB
Weight: 6.7 kg
Colour: Black
Maximum scan size: 216 x 5994 mm
Scanner type: Flatbed & ADF scanner
Sensor type: CCD

Brand: Brother
Category: Scanner
Model: PDS-5000F
Part number: PDS-5000F
EAN / UPC: 012502642701, 4977766754798
Also known as: Brother PDS-5000F scanner Flatbed & ADF scanner 600 x 600 DPI A4 Black

Specifications

61 specifications in 16 groups

Scanning

Specification	Value
Maximum scan size	216 x 5994 mm
Optical scanning resolution	600 x 600 DPI
Colour scanning	Yes
Duplex scanning	Yes
Input colour depth	48 bit
Output colour depth	24 bit
Greyscale levels	256
ADF scan speed (b/w, A4)	60 ppm
ADF scan speed (colour, A4)	60 ppm
Black/white scanning colour modes	Monochrome

Design

Specification	Value
Scanner type	Flatbed & ADF scanner
Built-in display	No
Product colour	Black
Display	LCD

Performance

Specification	Value
Sensor type	CCD
Light source	LED
Scan file formats	BMP, DOC, HTM, JPG, PDF, PNG, RTF, TIFF, TXT, XLS, XPS
Scan to	E-mail, FTP, File, HTTP, Image, OCR
Scan drivers	ICA, SANE, TWAIN, WIA
Scanning noise level	55 dB
Internal memory	512 MB
Built-in processor	Avision Vision Max II
Processor frequency	240 MHz

Input capacity

Specification	Value
Auto document feeder (ADF) input capacity	100 sheets

Paper handling

Specification	Value
Maximum ISO A-series paper size	A4
Scanning media types supported	Labels, Plastic Card, Thin paper
Auto Document Feeder (ADF) media weight	28 - 400 g/m²

Ports & interfaces

Specification	Value
USB port	Yes
USB version	3.2 Gen 1 (3.1 Gen 1)
Standard interfaces	USB 3.2 Gen 1 (3.1 Gen 1)

Power

Specification	Value
Power consumption (typical)	53 W
Power supply type	AC
Power consumption (standby)	17.6 W
Power consumption (off)	0.3 W
Power consumption (PowerSave)	2.7 W

Weight & dimensions

Specification	Value
Width	438 mm
Depth	380 mm
Height	725 mm
Weight	6.7 kg

Packaging data

Specification	Value
Package width	730 mm
Package depth	439 mm
Package height	386 mm
Package weight	9.2 kg

Packaging content

Specification	Value
Cables included	USB
Drivers included	Yes

Sustainability

Specification	Value
Sustainability certificates	ENERGY STAR

System requirements

Specification	Value
Linux operating systems supported	Debian 5.0, Debian 5.0.1, Debian 5.0.2, Debian 5.0.3, Debian 6.0, Debian 7.0, Debian 8.0, Fedora 11, Fedora 12, Fedora 13, Fedora 14, Fedora 15, Fedora 18, Fedora 6, Fedora 7, Fedora 8, Fedora 9, SuSE Linux 10, SuSE Linux 10.2, SuSE Linux 10.3, SuSE Linux 11, SuSE Linux 11.1, SuSE Linux 11.2, SuSE L
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Windows operating systems supported	Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows

Operational conditions

Specification	Value
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80%

Other features

Specification	Value
Spare part retention	5 year(s)

Technical details

Specification	Value
Pallet type	1200 x 1000 mm

Logistics data

Specification	Value
Products per pallet	12 pc(s)
Country of origin	China
Harmonized System (HS) code	84716070
Layers per pallet	4 pc(s)
Master (outer) cases per pallet	12 pc(s)
Master (outer) cases per pallet layer	3 pc(s)
Pallet gross height	16.3 cm
Pallet gross weight	195.6 kg
